Suzuki DR-Z400SM (2008) FUEL TANK (MODEL K7/K8) Diagram

#

Description
Price

1

TANK ASSY, FUEL (YELLOW) | MODEL K7 FOR YU1

49100-29FC0-YU1

Unavailable

1

TANK ASSY, FUEL (YELLOW) | MODEL K7 E33 FOR YU1; Includes Item(s) 2

49100-29FD0-YU1

Unavailable

2

TAPE SET | MODEL K7 FOR YU1

68110-29FH0-DUN

Unavailable

3

TANK ASSY,FUEL | MODEL K7 FOR 019 This part replaces 49100-29FF0-019.

44110-29F10-13L

$854.12

3

TANK ASSY, FUEL (BLUE) | MODEL K7 FOR N9J

49100-29FF0-YC2

Unavailable

3

TANK ASSY, FUEL (BLACK) | MODEL K7 E33 FOR 019

49100-29FG0-019

Unavailable

3

TANK ASSY, FUEL (BLUE) | MODEL K7 E33 FOR N9J; Includes Item(s) 4 - 4

49100-29FG0-YC2

Unavailable

4

TAPE SET | MODEL K7 FOR 019

68110-29FJ0-DVS

Unavailable

4

TAPE SET | MODEL K7 FOR YC2

68110-29FJ0-DVT

Unavailable

5

TANK ASSY, FUEL (BLACK) | MODEL K8 FOR 019

49200-29F00-019

Unavailable

5

TANK ASSY, FUEL (WHITE) | MODEL K8 FOR 30H

49100-29FP0-30H

Unavailable

5

TANK ASSY, FUEL (BLACK) | MODEL K8 E33 FOR 019

49200-29F10-019

Unavailable

5

TANK ASSY, FUEL (WHITE) | MODEL K8 E33 FOR 30H; Includes Item(s) 6 - 6

49100-29FQ0-30H

Unavailable

6

TAPE SET | MODEL K8 FOR 019

68120-29F10-FCM

Unavailable

6

TAPE SET | MODEL K8 FOR 30H

68120-29F00-FCR

Unavailable

7

CAP SET FUEL TANK FILLER | MODEL K7/K8 This part replaces 44200-29820.

44200-29821

$140.27

7

CAP SET,FUEL TA | MODEL K7/K8 E33 This part replaces 44200-05820.

44200-05822

$74.48

8

MOLDING, FRONT

68241-04X50-300

$7.32

9

CUSHION, FRONT

09329-10016

$3.10

10

CUSHION, UPPER

44541-29F00

$34.55

11

CLAMP

09407-30402

$4.11

12

SHIELD, FUEL TANK

44194-29F00

Unavailable

13

SCREW

02112-1630B

$3.08

14

SPACER

09180-06215

$7.95

15

CUSHION, SIDE

45149-14D00

$6.63

16

SPACER

09180-06306

$2.03

17

BOLT, REAR

09116-06172

$2.50

18

CUSHION, UPPER

09320-14022

$3.63

19

CUSHION (9X24X18) This part replaces 09320-10020.

09320-10071

$2.60

20

SPACER

09180-06271

$2.35
