Description

Price

1

PEDAL, BRAKE

43110-43D00

$17.32

2

ARM, BRAKE PEDAL | Includes Item(s) 3

43120-29F10

$279.42

3

OIL SEAL

09284-15006

$3.21

4

PIN

09200-06062

$2.19

5

SPRING

09444-11006

$2.92

6

.COTTER PIN This part replaces 04111-20158.

04111-2015A

$1.22

7

SHAFT, BRAKE PEDAL

43142-27C00

$21.12

8

WASHER

08211-10261

$2.01

9

COTTER PIN This part replaces 04111-20208.

04111-2020A

$1.22

10

SPRING, PEDAL RETURN

09443-11033

$4.07

11

BOLT, BRAKE SWITCH

09104-06004

$4.62

12

NUT This part replaces 08310-00063.

08310-0006A

$1.83

Suzuki DR-Z400S (2004) REAR BRAKE Diagram
