Suzuki DR-Z250 (2007) TRIM METER Diagram

#

Description
Price

1

TRIP METER ASSY (MILE)

34721-05D20

$203.42

1

TRIP METER ASSY (KILO) | E28

34721-05D30

Unavailable

2

BRACKET

34725-14D00

$48.38

3

CUSHION This part replaces 34726-05D20.

34726-05D21

$4.07

4

WASHER (4.3X14X0.8)

09160-04022

$2.15

5

NUT

08310-00047

$2.23

6

BOLT (6X25)

09118-06086

$3.15

7

SPACER (6.1X8X9.5)

09180-06248

$2.12

8

CUSHION

09320-08501

$3.23

9

CABLE ASSY,SPEE This part replaces 34910-12E00.

34910-12E01

$48.67

10

GUIDE, METER CABLE NO.1

34938-14D21

$8.65

11

GUIDE METER CABLE NO.2

34938-14D30

$10.63

12

BOLT (6X20)

09116-06168

$2.50

13

WASHER, NO.1 (6.5X18X1.6)

09160-06109

$1.49

14

WASHER (6.3X16X1) This part replaces 09169-06054.

09169-06053

$1.49

15

.SCREW

02112-0516A

$1.49

16

SCREW, NO.1

02142-0616A

$1.49

17

NUT, NO.1

08310-0006A

$1.84
