Suzuki DR-Z250 (2007) STEERING STEM (E28) Diagram

#

Description
Price

1

STEM, STEERING | Includes Item(s) 2

51410-13EB0

Unavailable

2

.BEARING (30X52X16) This part replaces 09265-30014.

09265-30035

$46.72

3

GUIDE, CABLE LOWER LH

51453-13E50

Unavailable

4

BOLT

01550-08407

$3.42

5

.BEARING (30X52X16) This part replaces 09265-30014.

09265-30035

$46.72

6

NUT STEERING

51631-28E00

$28.88

7

HEAD, STEERING STEM

51311-13E00

Unavailable

8

GUIDE, CABLE UPPER LH

51288-13E40

$37.15

9

BOLT

01550-08407

$3.42

10

HOLDER, HANDLE

56211-13EB0

Unavailable

11

BOLT, HOLDER

51321-13E00

Unavailable

12

WASHER,STEM HEAD

51356-29E00

$15.29

13

NUT

51353-27C40

$27.87

14

BRACKET, FR SIDE FR RH

35956-13E00

Unavailable

15

BRACKET, FR SIDE RR LH

35957-13E00

Unavailable
