Suzuki DR-Z125 (2007) FUEL TANK (MODEL K6) Diagram

#

Description
Price

1

TANK, FUEL (YELLOW) | FOR YU1

44100-08G40-YU1

Unavailable

1

TANK, FUEL (BLUE) | FOR HU8; Includes Item(s) 2 - 6

44100-08G50-YBH

Unavailable

2

TAPE SET | FOR YU1

68110-08G40-CEZ

Unavailable

2

TAPE SET | FOR YBH

68110-08G50-CLU

Unavailable

3

BRACKET, FRONT

44131-27C01

$16.77

4

BOLT This part replaces 01547-06123.

01547-0612B

$1.22

5

HOOK, SEAT FR

44132-27C01

$19.39

6

SCREW This part replaces 02142-06203.

02142-0620A

$1.38

7

CAP ASSY, FUEL TANK FILLER This part replaces 44200-29F00.

44200-29F01

$35.08

8

TUBE, FILLER INLET

44199-19A00

$5.91

9

HOSE,5X10X600 This part replaces 09352-50823-600.

44421-13ER0

$9.08

10

COVER,FUEL TANK | FOR YU1 This part replaces 44171-08G00-YU1.

44171-08G10-YU1

$64.88

10

COVER, TANK FRONT RH (BLUE) | FOR HU8

44171-08G00-YJ4

Unavailable

11

COVER,FUEL TANK | FOR YU1 This part replaces 44181-08G00-YU1.

44181-08G10-YU1

Unavailable

11

COVER, TANK FRONT LH (BLUE) | FOR HU8

44181-08G00-YJ4

Unavailable

12

TAPE, FRONT COVER RH | FOR YU1

68115-08G30-CET

Unavailable

12

TAPE, FRONT COVER RH | FOR HU8

68115-08G30-CLV

Unavailable

13

TAPE, FRONT COVER LH | FOR YU1

68116-08G30-CET

Unavailable

13

TAPE, FRONT COVER LH | FOR HU8

68116-08G30-CLV

Unavailable

14

BOLT This part replaces 01547-06123.

01547-0612B

$1.22

15

WASHER

09169-06060

$2.00

16

CUSHION, FUEL TANK

44541-13E10

$30.18

17

CUSHION, SIDE

44541-08G00

Unavailable

18

CLAMP

09407-30402

$3.76

19

CUSHION, REAR

44542-08G00

Unavailable

20

BAND, REAR

44560-44E00

$12.53

21

SCREW This part replaces 02142-06163.

02142-0616A

$1.37

22

SPACER

09180-06268

$2.10

23

CUSHION

44511-08G00

$9.67

24

BOLT, FINAL GEAR CASE COVER This part replaces 01547-06253.

01547-0625B

$2.43

25

WASHER

09160-06114

$2.01
