Suzuki DR-Z110 (2005) CAMSHAFT/TENSIONER Diagram

#

Description

Price

12046

SPROCKET,CAM CHAIN,36T

K1204-61206

Unavailable

12048

TENSIONER-ASSY

K1204-81164

Unavailable

12053

GUIDE-CHAIN,LOO This part replaces K1205-31397.

K1205-30185

Unavailable

12053A

GUIDE-CHAIN

K1205-31461

Unavailable

49118

CAMSHAFT-COMP

K4911-81214

Unavailable

92057

CHAIN,CAM

K9205-70032

Unavailable

92150

BOLT,TENSIONER

K9215-01380

Unavailable

92152

COLLAR,CHAIN GUIDE

K9215-21369

Unavailable

120

BOLT-SOCKET,6X1 This part replaces KK120-P0612.

K120C-A0612

$1.78

132

BOLT-FLANGED-SM This part replaces KK132-G0625.

K132B-A0625

$1.97

132A

BOLT-FLANGED-SMALL

KK132-Y0625

Unavailable

670

O RING

KK670-D2010

Unavailable

670A

O RING,21MM

KK670-D2021

Unavailable
