2022 Suzuki DL650AM2 Front Fender Diagram

← All diagrams

Find the part on the Front Fender diagram for your 2022 Suzuki DL650AM2, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2022 Suzuki DL650AM2 Front Fender Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

FENDER, FRONT

53110-28K00-291

1
Out of stock

2

.TAPE, FR FENDER

53121-28K00

2
Out of stock

3

BOLT

45241-17K10

2
Out of stock

4

NUT, FR FENDER

53122-06G00

2
Out of stock

5

BOLT (6X30)

09106-06122

2
Out of stock

6

WASHER

53121-33E00

2
Out of stock
