Description

Price

1

WHEEL, FRONT (19M/CXMT2.50) | FOR YAY/YME This part replaces 54111-27G20-019.

54111-27G40-019

$978.60

1

WHEEL,FR(19M/CX | FOR YHG/YPA This part replaces 54111-27G20-YD8.

54111-27G40-YD8

Unavailable

2

BEARING This part replaces 08133-62037.

08133-6203B

$17.61

3

OIL SEAL (24X40X7)

09282-24004

$6.57

4

RING, SPEED SENSOR FR

54162-27G00

$140.15

5

BOLT

07130-0512A

$2.19

6

AXLE, FR

54711-08F10

$108.15

7

SPACER (17.5X25X88)

09180-17067

$23.05

8

DISC,FR BRAKE

59210-44G11

$415.82

9

BOLT (8X21)

09106-08160

$3.57

10

TIRE,FR(110/80R | TRAIL WING 101 RADIAL This part replaces 55110-06G10.

55110-06G12

$185.88

11

VALVE ASSY, WHEEL RIM

43130-24A00

$8.85

12

BALANCER, WHEEL NO.1

43222-73H10

$5.82

12

BALANCER, WHEEL NO.2

43224-73H10

$5.50

12

BALANCER, WHEEL NO.3

43226-73H10

$6.42

Suzuki DL650AL1 (2011) FRONT WHEEL (DL650A L1 E33) Diagram
