Suzuki DL1000 (2006) TURNSIGNAL LAMP (MODEL K4/K5/K6) Diagram

#

Description
Price

1

LAMP ASSY, FRONT TURNSIGNAL RH

35601-27G00

$83.16

2

LAMP ASSY, FRONT TURNSIGNAL LH | Includes Item(s) 3 - 7

35602-27G00

$82.75

3

LENS, RH

35612-31F30

$13.90

4

LENS, LH

35632-31F30

$14.37

5

SCREW This part replaces 03242-04163.

03242-0416B

$2.93

6

BULB (12V,21W)

09471-12045

$3.27

7

PIN

09202-04017

$3.78

8

WASHER

09160-12092

$2.19

9

NUT This part replaces 08316-10123.

08316-1012A

$2.26

10

LAMP ASSY, REAR TURNSIGNAL RH

35603-06G10

Unavailable

11

LAMP ASSY, REAR TURNSIGNAL LH | Includes Item(s) 12 - 16

35604-06G10

Unavailable

12

LENS, RH

35632-31F30

$14.37

13

LENS, LH

35612-31F30

$13.90

14

SCREW This part replaces 03242-04163.

03242-0416B

$2.93

15

BULB (12V,21W)

09471-12045

$3.27

16

PIN

09202-04017

$3.78

17

NUT This part replaces 08316-10123.

08316-1012A

$2.26

18

RELAY ASSY,TURNSIGNAL LAMP This part replaces 38610-03F00.

38610-03F01

$87.08
