Honda CT125A (77) TRAIL 125, JPN, VIN# CT125-1010366 WIRE HARNESS + IGNITION COIL Diagram

#

Description
Price

1

GROMMET A, AIR CLEANER HOUSING

17247-240-000

$2.92

2

NUT, FLANGE (6MM) This part replaces 18362-720-000.

94050-06000

$1.49

2

NUT, FLANGE (6MM)

94050-06000

$1.49

3

CONDENSER ASSY. (TOYO)

30250-052-156

Unavailable

4

COIL, IGNITION This part replaces 30500-355-003.

30500-950-405

$118.02

4

COIL, IGNITION

30500-950-405

$118.02

4

COIL, IGNITION This part replaces 30530-355-003.

30500-950-405

$118.02

5

BRACKET, IGNITION COIL This part replaces 30530-355-010.

30540-355-010

Unavailable

5

BRACKET, IGNITION COIL

30540-355-010

Unavailable

6

CAP ASSY., NOISE SUPPRESSOR | Use up to Frame SN 1016667 This part replaces 30600-918-670.

30700-KE2-942

$17.87

6

CAP ASSY., NOISE SUPPRESSOR | Use up to Frame SN 1016667 This part replaces 30700-152-153.

30700-KE2-942

$17.87

6

CAP ASSY., NOISE SUPPRESSOR | Use up to Frame SN 1016667 This part replaces 30700-152-163.

30700-KE2-942

$17.87

7

RECTIFIER ASSY., SILICON (SHINDENGEN) This part replaces 31700-124-003.

31700-124-008

$29.71

8

WIRE HARNESS (NOT AVAILABLE)

32100-401-680

Unavailable

9

CLIP, IGNITION CABLE (NOT AVAILABLE)

32906-355-000

Unavailable

10

CLIP, COMBINATION SWITCH WIRE (NOT AVAILABLE)

32908-107-700

Unavailable

11

LOCK SET (NOT AVAILABLE) This part replaces 35010-382-000.

35010-382-770

Unavailable

11

LOCK SET (NOT AVAILABLE)

35010-382-770

Unavailable

12

SWITCH ASSY., COMBINATION (NOT AVAILABLE)

35100-382-671

Unavailable

13

BRACKET, MAIN SWITCH (NOT AVAILABLE)

50375-331-000

Unavailable

14

GUIDE, CLUTCH CABLE

50721-382-670

Unavailable

15

RUBBER, BRACKET CUSHION

84705-292-000

$2.79

16

COLLAR, NUMBER BRACKET SETTING

84706-286-000

$2.99

17

BOLT, FLANGE (6X25)

90122-369-000

$6.97

18

BOLT, HEX. (6X25) This part replaces 92000-06025.

92101-06025-0A

$1.62

18

BOLT, HEX. (6X25) This part replaces 92000-06025-0A.

92101-06025-0A

$1.62

18

BOLT, HEX. (6X25) This part replaces 92100-06025.

92101-06025-0A

$1.62

18

BOLT, HEX. (6X25)

92101-06025-0A

$1.62

19

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

19

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

19

WASHER, PLAIN (6MM)

94101-06800

$1.49

20

BAND A2, CABLE

95014-61200

$2.33

21

BAND A3, CABLE

95014-61300

$1.97

22

BAND B1, CABLE

95014-62100

$1.64
