Honda CT125A (77) TRAIL 125, JPN, VIN# CT125-1010366 HEADLIGHT + HORN Diagram

#

Description
Price

1

RUBBER, AIR CLEANER HOUSING SETTING

17245-107-010

$2.89

2

CABLE A, SUB (NOT AVAILABLE)

32101-385-000

Unavailable

3

CABLE B, SUB (WHITE) (NOT AVAILABLE)

32102-385-000

Unavailable

4

SUB-WIRE (RED/WHITE)

32111-401-670

Unavailable

5

WIRE HARNESS ASSY., FR.

32150-401-680

Unavailable

6

HEADLIGHT ASSY. (NOT AVAILABLE) This part replaces 33100-243-670.

33100-243-672

Unavailable

6

HEADLIGHT ASSY. (NOT AVAILABLE)

33100-243-672

Unavailable

7

RIM, HEADLIGHT

33101-243-670

$33.52

8

SCREW, UNIT HOLDER (NOT AVAILABLE)

33102-283-000

Unavailable

9

SCREW, HEADLIGHT BEAM ADJ.

33103-200-020

Unavailable

10

SPRING, HEADLIGHT BEAM ADJUSTING

33107-200-023

$3.01

11

SUB-WIRE, HEADLIGHT (NOT AVAILABLE)

33109-382-670

Unavailable

12

NUT, HEADLIGHT BEAM ADJ. (NOT AVAILABLE)

33117-200-023

Unavailable

13

HEADLIGHT UNIT (6V35/25W) This part replaces 33120-243-670.

33120-243-672

$62.34

13

HEADLIGHT UNIT (6V35/25W)

33120-243-672

$62.34

14

NUT, UNIT HOLDER

33128-200-033

Unavailable

15

RESISTOR (NOT AVAILABLE)

35400-329-671

Unavailable

16

HORN ASSY. (NOT AVAILABLE)

38100-401-681

Unavailable

17

SUB-WIRE, HORN

38105-312-670

Unavailable

18

COLLAR, FR. FENDER (WHITE) This part replaces 61104-357-000.

61104-428-010

$4.42

18

COLLAR, FR. FENDER (WHITE) This part replaces 61104-428-000.

61104-428-010

$4.42

18

COLLAR, RR. FENDER

61105-428-000

Unavailable

19

CASE, HEADLIGHT *NH43* (PHANTOM BLACK) (NOT AVAILABLE) This part replaces 61301-391-000NR.

61301-391-000ZA

Unavailable

19

CASE, HEADLIGHT *NH43* (PHANTOM BLACK) (NOT AVAILABLE)

61301-391-000ZA

Unavailable

20

WASHER, HEADLIGHT CASE (NOT AVAILABLE)

61303-074-000

Unavailable

21

NUT, HEADLIGHT CASE

61303-105-000

$3.81

22

BRACKET, HEADLIGHT CASE *A01* (MAT BLACK) (NOT AVAILABLE)

61311-401-680ZA

Unavailable

23

RUBBER, BRACKET SETTING

61316-361-000

Unavailable

24

BOLT, FLANGE (8X25) (NOT AVAILABLE)

90119-383-000

Unavailable

25

BOLT, HEX. (6X12) This part replaces 92000-06012.

92101-06012-0A

$1.49

25

BOLT, HEX. (6X12) This part replaces 92000-06012-0A.

92101-06012-0A

$1.49

25

BOLT, HEX. (6X12) This part replaces 92100-06012.

92101-06012-0A

$1.49

25

BOLT, HEX. (6X12) This part replaces 92101-06012.

92101-06012-0A

$1.49

25

BOLT, HEX. (6X12)

92101-06012-0A

$1.49

26

BOLT, HEX. (6X25) This part replaces 92000-06025.

92101-06025-0A

$1.62

26

BOLT, HEX. (6X25) This part replaces 92000-06025-0A.

92101-06025-0A

$1.62

26

BOLT, HEX. (6X25) This part replaces 92100-06025.

92101-06025-0A

$1.62

26

BOLT, HEX. (6X25)

92101-06025-0A

$1.62

27

SCREW, PAN (5X12)

93500-05012-0A

$1.49

28

SCREW-WASHER (5X55) (NOT AVAILABLE)

93893-05055-00

Unavailable

29

SCREW, TAPPING (4X8) (NOT AVAILABLE)

93901-24110

Unavailable

30

NUT, HEX. (8MM)

94001-08000-0S

$1.49

31

WASHER, PLAIN (4MM)

94101-04000

$1.49

32

WASHER, PLAIN (4MM)

94101-04800

$1.49

33

WASHER, PLAIN (5MM)

94101-05000

$1.49

34

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

34

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

34

WASHER, PLAIN (6MM)

94101-06800

$1.49

35

WASHER, SPRING (5MM)

94111-05000

$1.49

36

PIN, LOCK (5MM)

94251-05000

$1.49
