Kawasaki CSR Twin VALVES Diagram
#
12004
VALVE,INLET
12004-014
Unavailable
12005
VALVE,EXHAUST
12005-007
Unavailable
12009
RETAINER,VALVE SPRING
12009-007
Unavailable
12011
COLLAR,VALVE SPRING
12011-003
Unavailable
12032
TAPPET
12032-006
Unavailable
49078
SPRING,OUTER VALVE
12007-015
Unavailable
49078A
SPRING,INNER VALVE
12007-016
Unavailable
92022
WASHER,PLAIN
92022-309
$4.68
92025
SHIM,2.20T
12037-051
Unavailable
92025A
SHIM,2.25T
12037-052
Unavailable
92025B
SHIM,2.30T
12037-053
Unavailable
92025C
SHIM,2.35T
12037-054
Unavailable
92025D
SHIM,2.40T
12037-055
Unavailable
92025E
SHIM,2.45T
12037-056
Unavailable
92025F
SHIM,2.50T
12037-057
Unavailable
92025G
SHIM,2.55T
12037-058
Unavailable
92025H
SHIM,2.60T
12037-059
Unavailable
92025I
SHIM,2.65T
12037-060
Unavailable
92025J
SHIM,2.70T
12037-061
Unavailable
92025K
SHIM,2.75T
12037-062
Unavailable
92025L
SHIM,2.80T
12037-063
Unavailable
92025M
SHIM,2.85T
12037-064
Unavailable
92025N
SHIM,2.90T
12037-065
Unavailable
920250
SHIM,2.95T
12037-066
Unavailable
92025P
SHIM,3.00T
12037-067
Unavailable
92025Q
SHIM,3.05T
12037-068
Unavailable
92025R
SHIM,3.10T
12037-069
Unavailable
92025S
SHIM,3.15T
12037-070
Unavailable
92025T
SHIM,3.20T
12037-071
Unavailable
92025U
SHIM,3.25T
12037-072
Unavailable
92025V
SHIM,3.30T
12037-073
Unavailable
92025W
SHIM,3.35T
12037-074
Unavailable
92025X
SHIM,3.40T
12037-075
Unavailable
92049
OIL SEAL,VALVE
92049-017
Unavailable
