Honda CRF450XAC (13) CRF450X, JPN, VIN# JH2PE061-DK300001 TO JH2PE061-DK399999 HANDLEBAR + TOP BRIDGE (2) Diagram

#

Description
Price

3

GUIDE, FR. BRAKE HOSE

45468-KS7-830

$15.20

4

STAY, CONNECTOR

50130-MEY-A20

$24.67

5

RING, STOPPER

52487-MEN-A11

$9.65

6

HANDLEBAR

53100-MEN-670

$113.88

7

PROTECTOR, HANDLE

53121-MEN-671

$43.38

8

HOLDER, HANDLE (LOWER) | (Optional).

53132-KA3-831

$27.45

8

HOLDER, HANDLE (LOWER)

53132-KZ4-J20

$27.45

9

CUSHION, HANDLEBAR

53133-KA3-832

$4.26

10

BRIDGE, FORK TOP

53300-MEY-A20

$219.29

11

DAMPER ASSY., STEERING

53700-MEY-A21

$410.03

12

CASE, DAMPER

53701-MEY-A21

$114.68

13

BOLT, PLUG

53711-MEN-A11

$29.93

14

PIECE, ADJUST

53712-MEN-A11

$8.90

15

ROD, PISTON

53721-MEY-A21

$180.94

16

BEARING

53731-MEN-A11

$80.30

17

PISTON, FREE

53754-MEN-A11

$9.10

18

SPRING, RETURN

53755-MEN-A11

$5.84

19

WASHER

53756-MEY-A21

$4.10

20

CAP, END

53757-MEN-A11

$8.09

21

WASHER

53758-MEY-A21

$4.10

22

COLLAR, STEERING DAMPER

53782-MEY-A20

$4.94

23

COLLAR, STEERING DAMPER TOP

53783-MEY-A20

$3.91

24

EMBLEM, PRODUCT (MARUI)

86150-KPG-901

$3.37

25

BOLT, FLANGE (6X16)

90106-MJ0-000

$2.80

26

BOLT, FLANGE (8X45)

90107-KZ4-J40

$1.94

27

BOLT, FLANGE (8X35)

90124-KZ4-J40

$2.06

28

BOLT (7X35.0)

90125-MEY-A20

$4.10

29

NUT, STEERING STEM

90304-KZ4-J30

$7.38

30

NUT, U (10MM)

90306-KZ4-711

$3.49

31

WASHER, STEERING STEM

90503-KZ4-J40

$1.42

32

WASHER, PLAIN (10MM)

90507-KA3-830

$3.49

33

CIRCLIP (23.5)

90651-MEN-A11

$3.46

34

CIRCLIP (17.3)

90652-MEN-A11

$3.32

35

O-RING (18.8X1.9)

91258-KZ3-B01

$2.48

36

O-RING (9.5X1.5)

91351-MEN-A11

$1.88

37

O-RING (11X1.9)

91352-MEN-A11

$1.74

38

O-RING (13.5X1.5)

91353-MEN-A11

$1.88

41

HOLDER B1, HANDLEBAR (UPPER)

95014-22100

$10.90

42

BOLT, FLANGE (6X10)

96001-06010-00

$1.48
