Description

Price

1

COLLAR, WATER PASS

11102-MKE-A00

$4.46

2

COVER ASSY., R. CRANKCASE

11330-MKE-A00

$350.52

3

COVER, CLUTCH

11351-MKE-A00

$134.02

4

GASKET, CLUTCH COVER

11352-MKE-A00

$12.99

5

GASKET, R. COVER

11394-MKE-A01

$15.62

6

IMPELLER, WATER PUMP

19215-MEN-850

$42.58

7

SEAL, MECHANICAL

19217-KRN-A61

$46.40

8

COVER, WATER PUMP

19220-MKE-A00

$109.21

9

GASKET, WATER PUMP

19226-MKE-A00

$5.12

10

SHAFT, WATER PUMP

19241-MKE-A00

$60.22

11

BOLT, FLANGE (6X35) (SH)

90023-MKE-A00

$2.85

12

BOLT, FLANGE (6X65) (SH)

90027-MKE-A00

$3.41

13

BOLT, FLANGE (6X75) (SH)

90028-MKE-A00

$3.41

14

CAP (30MM)

90087-HB5-000

$16.69

15

BOLT (6X28)

90107-MEN-A60

$2.62

16

BOLT (6X25)

90109-MEN-A70

$2.79

17

WASHER, SEALING (7MM)

90447-KE1-000

$2.66

18

WASHER, SEALING (6.5MM)

90463-ML7-000

$2.92

19

BEARING, BALL (12X24X6)

91002-MEN-A31

$8.83

20

OIL SEAL (12X22X5) This part replaces 91201-148-003.

91201-965-000

$4.06

20

OIL SEAL (12X22X5)

91201-965-000

$4.06

22

O-RING (2.4X19)

91301-MKE-A00

$2.07

23

O-RING (27X2) (ARAI)

91305-KF0-003
