Description

Price

1

BOLT, SEALING (16MM)

12206-881-310

$5.39

2

RADIATOR, R.

19010-KSC-A11

$302.39

2

RADIATOR, R. This part replaces 19010-KSC-305.

19010-KSC-A11

$302.39

3

RADIATOR, L.

19015-KSC-A11

$227.02

3

RADIATOR, L. This part replaces 19015-KSC-305.

19015-KSC-A11

$227.02

4

GRILLE, RADIATOR

19033-KRN-010

$36.57

5

CAP, RADIATOR

19037-KRN-641

$41.56

6

RUBBER, RADIATOR MOUNTING

19051-KRN-000

$2.67

7

COLLAR, RADIATOR MOUNTING

19052-MAC-680

$5.14

8

SEAL, RADIATOR CAP (ENGLISH/FRENCH/JAPANESE)

19055-KRN-641

$4.28

9

HOSE A, WATER

19061-KRN-000

$17.16

10

HOSE B, WATER

19062-KRN-000

$12.51

11

HOSE D, WATER

19064-KRN-000

$9.46

12

TUBE, RADIATOR BREATHER

19104-KSC-000

$14.00

13

CAP, RESERVE TANK

19104-ME9-000

$16.36

14

TUBE, RESERVE TANK DRAIN

19105-KSC-A10

$18.36

15

CAP ASSY., RESERVE TANK

19105-MG8-000

$12.95

16

GASKET, RESERVE TANK

19107-MG8-000

$5.05

17

TANK, RADIATOR RESERVE (COO) This part replaces 19110-KSC-000.

19110-KSC-305

$37.74

17

TANK, RADIATOR RESERVE (COO)

19110-KSC-305

$37.74

18

CLAMP B, WATER HOSE

19506-KS6-700

$7.50

19

GUIDE, MAIN HARNESS

50129-MEY-A10

$17.33

20

BOLT, FLANGE (6X23.5)

90001-GB4-000

$1.90

21

NUT, CLIP (6MM)

90303-KRN-000

$2.67

22

WASHER, RADIATOR MOUNTING

90403-KA3-830

$2.36

23

COLLAR, GEARSHIFT LEVER SETTING

90522-170-700

$1.84

25

O-RING (13.5X1.4)

91307-PH7-660

$2.83

25

O-RING (13.5X1.4) This part replaces 91307-611-000.

91307-PH7-660

$2.83

26

CLIP, WIRE

91406-166-000

$3.83

27

NUT, FLANGE (6MM)

94050-06000

$1.49

28

CLIP, TUBE (B8)

95002-02080

$1.80

29

CLIP, TUBE (B10)

95002-02100
