Description

Price

1

SPOKE SET, RR. (INSIDE)

06420-KRN-710

$3.92

2

SPOKE SET, RR. (OUTSIDE)

06421-KRN-710

$3.92

3

SPROCKET, FINAL DRIVEN (49T) | (Optional).

41201-KZ3-J40

$122.82

3

SPROCKET, FINAL DRIVEN (48T)

41202-KZ3-J40

$122.82

3

SPROCKET, FINAL DRIVEN (50T) | (Optional).

41203-KZ3-J20

$110.41

4

RETAINER, RR. WHEEL BEARING

41231-KZ4-J20

$19.28

5

AXLE, RR. WHEEL

42301-KRN-A30

$47.01

6

COLLAR, L. RR. AXLE This part replaces 42305-KRN-A30.

42305-MKE-A50

$21.38

7

COLLAR, R. RR. AXLE

42306-KZ4-J20

$19.28

8

COLLAR, RR. WHEEL SIDE

42311-KRN-A30

$22.99

9

COLLAR, RR. WHEEL DISTANCE

42620-KZ4-J20

$27.72

10

HUB SUB-ASSY., RR.

42635-KRN-710

$325.54

11

WHEEL SUB-ASSY., RR.

42650-KRN-A40

$892.44

12

RIM, RR. WHEEL (19X1.85)

42701-KRN-A41

$280.16

13

TIRE, RR. (100/90-19 57M) (DUNLOP) (NOT AVAILABLE)

42711-KSR-J01

Unavailable

14

CAP, VALVE

42714-KA3-710

$10.46

15

STOPPER, BEAD (1.85) STOPPER, BEAD (1.85B)

42715-KA2-680

$32.27

16

DISK, RR. BRAKE

43351-KRN-A30

$216.62

17

TUBE, TIRE (DUNLOP) (NOT AVAILABLE)

44712-300-004

$65.43

18

FLAP, TIRE (DUNLOP) This part replaces 44713-300-004.

42713-KZ3-611

$5.90

19

BOLT, DISK (6X19)

90105-MAC-680

$4.99

20

SCREW, FLAT (8X31)

90125-KA4-000

$3.08

21

NUT, U (6MM) NUT, FLANGE (6MM)

90301-473-003

$4.07

22

NUT, U (22MM)

90305-KZ4-J20

$8.96

23

NUT, U (8MM) (FUSE RASHI)

90309-ML3-791

$4.35

24

WASHER (22X35X2)

90401-KZ4-J20

$2.89

25

WASHER (8MM)

90465-MC4-000

$2.51

26

BEARING, RADIAL BALL (69052RS)

91051-KZ4-J21

$18.42

27

BEARING, RADIAL BALL (6905RS)

91052-KZ4-J21

$17.35

28

DUST SEAL (32X43X7)

91251-KZ4-J21

$4.94

29

NUT, HEX. (8MM)

94001-08000-0S

$1.49

30

WASHER, SPRING (8MM)

94111-08000
