Description

Price

1

SWITCH ASSY., FR. STOP

35340-MGS-D31

$16.62

2

STAY, FR. SPEED SENSOR WIRE

38526-KZZ-J80

$6.33

3

HOSE A, FR. BRAKE

45124-KZZ-G41

$39.93

4

HOSE D, FR. BRAKE

45127-KZZ-G41

$92.32

5

CLAMP, FR. BRAKE HOSE

45181-KZZ-G40

$11.01

6

CLAMP B, FR. BRAKE HOSE

45182-KZZ-J80

$6.74

7

BOOT

45504-410-003

$10.93

8

MASTER CYLINDER SUB-ASSY., FR. BRAKE (COO) (NISSIN)

45510-KZZ-305

$66.84

8

MASTER CYLINDER SUB-ASSY., FR. BRAKE (COO) (NISSIN) This part replaces 45510-KZZ-901.

45510-KZZ-305

$66.84

9

CAP, MASTER CYLINDER

45513-HA2-006

$24.74

10

HOLDER, MASTER CYLINDER

45517-166-006

$12.17

11

SEPARATOR

45518-MEN-J01

$6.54

12

DIAPHRAGM

45520-MG7-006

$9.52

13

PLATE, DIAPHRAGM

45521-HA2-006

$9.75

14

RING

45523-KA3-731

$2.67

15

MASTER CYLINDER SET

45530-471-831

Unavailable

16

LEVER, R. HANDLEBAR (COO)

53175-KZZ-305

$9.66

16

LEVER, R. HANDLEBAR (COO) This part replaces 53175-KZZ-900.

53175-KZZ-305

$9.66

17

COVER, R. HANDLE LEVER

53176-KZZ-901

$4.84

18

BOLT, FLANGE (6X12)

96001-06012-00

$1.64

19

BOLT, FLANGE (6X22)

90013-GHB-660

$2.12

20

BOLT, FLANGE (6X25)

90013-GHB-670

$2.12

21

BOLT, HANDLE LEVER PIVOT

90114-166-006

$6.04

23

BOLT, OIL (10X22) (SAGA)

90145-MS9-612

$6.82

24

WASHER, OIL BOLT

90545-300-000

$3.72

25

CIRCLIP

90651-MA5-671

$2.38

26

SCREW, FLAT (4X12)

93600-04012-0G

$0.83

26

SCREW, FLAT (4X12) This part replaces 93600-04012-1G.
