Description

Price

1

SPOKE SET, RR.

06420-KSE-840

$3.63

2

SPROCKET, FINAL (56T) (SUNSTAR) | (Optional).

41201-GBF-K10

$123.53

2

SPROCKET, FINAL (55T) (SUNSTAR) | (Optional).

41201-GBF-860

$173.04

2

SPROCKET, FINAL DRIVEN (56T)

41201-KSE-840

$53.96

2

SPROCKET, FINAL (57T) (SUNSTAR) | (Optional).

41202-GBF-860

$141.88

3

AXLE, RR. WHEEL

42301-KSE-000

$25.19

4

COLLAR, RR. AXLE

42305-KSE-000

$16.34

5

COLLAR, RR. WHEEL SIDE

42311-KSE-000

$14.60

6

COLLAR, RR. WHEEL DISTANCE

42620-KSE-000

$8.75

7

HUB SUB-ASSY., RR.

42635-KSE-670

$197.87

8

WHEEL SUB-ASSY., RR.

42650-KSE-840

$513.78

9

RIM, RR. WHEEL

42701-KSE-841

$227.84

10

TIRE (90/100-16 52M)

42711-KSE-F62

$86.96

11

TUBE, TIRE (90/100-16) (DUNLOP)

42712-GBF-861

$33.07

12

FLAP, TIRE (1.85X16) (DUNLOP)

42713-GBF-861

$5.68

13

CAP, VALVE

42714-KA3-710

$9.60

14

STOPPER, BEAD (1.85) STOPPER, BEAD (1.85B)

42715-KA2-680

$29.63

15

DISK, RR. BRAKE

43351-KSE-000

$149.16

16

BOLT, DISK (6X17)

90105-KAE-870

$2.80

17

SCREW, FLAT (8X31)

90125-KA4-000

$2.95

18

NUT, U (16MM)

90305-GW2-711

$15.03

19

NUT, U (8MM) (FUSE RASHI)

90309-ML3-791

$4.16

20

WASHER (8MM)

90465-MC4-000

$2.32

21

WASHER (16MM)

90501-GBM-750

$0.94

22

BEARING, RADIAL BALL (6003)

91051-KSE-003

$11.05

23

DUST SEAL (23X35X7)

91205-VM6-003

$8.84

24

NUT, HEX. (8MM)

94001-08000-0S

$1.31

25

WASHER, SPRING (8MM)

94111-08000

Unavailable

26

CIRCLIP (INNER) (35MM)

94520-35000
