Description

Price

1

CUSHION ASSY., RR. (COO)

52400-KSE-306

$909.30

2

SPRING, RR. SHOCK ABSORBER (49.0N/MM,5.0KGF/MM) (SHOWA) | (Optional).

52401-KSE-A31

$163.10

2

SPRING, RR. SHOCK ABSORBER (51.0N/MM,5.2KGF/MM) (SHOWA)

52401-KSE-A41

$163.10

2

SPRING, RR. SHOCK ABSORBER (53.0N/MM,5.4KGF/MM) (SHOWA) | (Optional).

52402-KSE-A41

$170.46

3

DAMPER, RR. (COO)

52410-KSE-305

$602.15

4

ROD, PISTON

52421-KSE-A71

$358.95

5

ADJUSTER, SPRING

52422-MA0-003

$39.25

6

NUT, ADJUSTER

52423-GBF-831

$21.46

7

CAP, AIR VALVE

52425-381-771

$5.05

8

CASE, DAMPER

52425-KSE-671

$337.33

9

ROD

52426-KSE-A71

$295.56

10

RUBBER, STOPPER

52427-GBF-831

$15.72

11

CAP, CASE

52428-KA4-741

$20.05

12

CASE, ROD GUIDE

52429-KSE-A71

$37.08

13

RING, PISTON

52431-MA0-771

$16.40

14

O-RING (2.0X33.5)

52432-GBF-831

$4.46

15

O-RING (3.5X33.7)

52434-KA3-681

$5.36

16

RING, STOPPER

52435-MA0-771

$4.97

17

OIL SEAL SET

52436-KSE-680

$12.56

18

NUT, HEX. (12MM)

52438-KA4-741

$2.92

19

ADJUSTER, COMPRESSION DAMPING FORCE

52440-GBF-A01

$50.26

20

DIAPHRAGM

52451-GBF-831

$16.21

21

CAP, CHAMBER

52453-KSE-671

$16.38

22

STOPPER, SPRING SEAT

52455-GBF-831

$5.54

23

SEAT, SPRING

52459-GBF-831

$22.34

24

COLLAR D, CUSHION ARM

52462-KSE-000

$7.75

25

COLLAR B, CUSHION ARM

52463-KSE-000

$8.72

26

ARM SUB-ASSY., CUSHION

52465-KSE-000

$233.66

27

COLLAR A, CONNECTING ROD

52473-KSE-000

$11.23

28

COLLAR, CUSHION CONNECTING ROD

52473-KZ9-710

$15.97

29

ROD SUB-ASSY., CUSHION CONNECTING

52479-KSE-000

$200.51

30

COLLAR A, CUSHION (UPPER)

52486-GBF-830

$7.23

31

COLLAR B, CUSHION (UPPER)

52487-GBF-830

$6.19

32

LABEL, RR. DAMPER WARNING

87516-KZ1-600

$6.93

34

BOLT, FLANGE (10X85)

90101-KK6-000

$7.28

35

BOLT, FLANGE (10X105)

90101-KSE-000

$7.72

36

BOLT, FLANGE (10X67)

90128-KSE-000

$8.41

37

BOLT, LINK (10X73)

90153-KSE-000

$6.54

38

BOLT, CUSHION (LOWER) (10X43.5)

90153-KZ4-710

$9.38

39

NUT, U (10MM) (FUSE RASHI)

90304-GE8-003

$3.67

40

NUT, U (10MM)

90306-KZ4-711

$3.74

41

BEARING, NEEDLE (KOYO)

91071-KV3-005

$24.88

42

BEARING, NEEDLE (17X24X20) (NTN)

91072-KT7-003

$20.20

43

BEARING, NEEDLE (19X26X13)

91074-KRN-711

$8.50

44

BEARING, NEEDLE (16X22X12)

91077-GS2-702

$19.89

45

DUST SEAL (17X24X5) (ARAI)

91262-KV3-831

$6.21

46

DUST SEAL, RR. CUSHION (UPPER)

91351-GS2-701

$4.48

47

DUST SEAL (19X26X3)

91351-KSE-003
