Description

Price

1

MAINSHAFT (14T)

23210-KSE-670

$105.64

2

COUNTERSHAFT

23221-KSE-670

$116.59

3

GEAR, COUNTERSHAFT LOW (31T)

23411-KSE-670

$84.62

4

GEAR, MAINSHAFT SECOND (17T)

23421-KSE-670

$49.11

5

COLLAR (16.5MM)

23422-KSE-670

$7.18

6

GEAR, COUNTERSHAFT SECOND (28T)

23431-KSE-670

$79.15

7

COLLAR (20MM)

23432-KSE-670

$11.03

8

GEAR, MAINSHAFT THIRD (22T)

23441-KSE-670

$85.90

9

GEAR, COUNTERSHAFT THIRD (29T)

23451-KSE-670

$81.77

10

GEAR, MAINSHAFT FOURTH (19T)

23461-KSE-670

$70.84

11

GEAR, COUNTERSHAFT FOURTH (21T)

23471-KSE-670

$80.49

12

GEAR, MAINSHAFT FIFTH (23T)

23481-KSE-A70

$69.82

13

COLLAR (18MM)

23483-KSE-670

$8.20

14

GEAR, COUNTERSHAFT FIFTH (22T)

23491-KSE-670

$85.90

15

COLLAR, SPLINE (18X11.7)

23512-KSE-670

$7.36

16

SPROCKET, DRIVE (15T)

23801-KSE-670

$27.39

17

PLATE, DRIVE SPROCKET FIXING

23802-KSE-670

$7.46

18

BOLT, FLANGE SOCKET (6X14)

90071-MF5-000

$3.35

19

BOLT, DRIVE SPROCKET FIXING

90084-041-000

$4.62

20

WASHER, THRUST (18MM)

90401-KCZ-000

$1.89

21

WASHER, THRUST INVOLUTE (18X23X1.6)

90401-KSE-670

$2.07

22

WASHER, THRUST INVOLUTE (20X26X1)

90403-KSE-670

$2.07

23

PLATE, BEARING HOLDER

90441-KRM-840

$1.49

24

WASHER, THRUST (15MM)

90451-107-000

$1.49

25

WASHER, THRUST (16.5MM)

90452-437-000

$3.40

26

WASHER, THRUST (15X1)

90457-HB3-000

$2.89

27

WASHER, THRUST (20MM)

90554-728-940

$6.07

28

CIRCLIP (18MM)

90601-030-000

$1.77

29

CIRCLIP (20MM)

90601-459-000

$2.92

30

BEARING, RADIAL BALL (20X47X10.5)

91004-MT3-003

$19.13

31

BEARING, RADIAL BALL (6002U)

91008-KSE-671

$11.75

32

OIL SEAL (20X30X7)

91202-KCY-761

$5.71

33

BEARING, RADIAL BALL (6203)

96120-62030-00

$17.70

34

BEARING, RADIAL BALL (6202U)

96140-62020

$13.60

34

BEARING, RADIAL BALL (6202U) This part replaces 96140-62020-00.
