Honda CRF125FAC (17) CRF125F, CHN, VIN# LALJE031-H3300001 OIL PUMP Diagram

#

Description
Price

1

GASKET B, HEAD COVER

12396-KRM-840

$1.49

2

PUMP ASSY., OIL

15100-KYY-900

$90.02

3

GASKET, OIL PUMP

15119-KWS-901

$5.15

4

GEAR, OIL PUMP DRIVEN (23T)

15133-KYY-900

$36.18

5

ROTOR, OIL PUMP (INNER)

15331-KYY-900

$12.72

6

ROTOR, OIL PUMP (OUTER)

15332-KYY-900

$15.16

7

SCREEN, OIL FILTER

15421-KSP-910

$3.65

8

ROTOR, OIL FILTER

15431-KWS-900

$37.82

9

GASKET, OIL FILTER COVER This part replaces 15439-KWS-901.

15439-K26-901

$2.92

9

GASKET, OIL FILTER COVER

15439-K26-901

$2.92

10

COVER, OIL FILTER

15441-KWS-900

$29.46

11

NUT, SPECIAL FLANGE (14MM)

90202-KRM-840

$1.49

12

WASHER (14.2X26X3)

90432-KPT-A00

$1.85

13

WASHER (9.2MM)

90455-KWS-900

$2.79

14

PIN, DOWEL (8X14)

90702-KRM-840

$1.49

15

SCREW, TAPPING (4X8)

93901-34120

$1.49

16

E-RING (6MM)

94540-06018

$2.75

17

BOLT, FLANGE (6X14)

95701-06014-00

$1.49

18

BOLT, FLANGE (6X35)

96001-06035-00

$1.49

19

ROLLER (3X15.8)

96220-30158

$1.49
