Description

Price

1

GEAR, PRIMARY DRIVEN (81T)

22100-HL4-003

$668.54

2

CLUTCH ASSY.

22500-MJP-G81

$487.44

3

PIPE A, FEED

22711-MJP-G80

$17.85

4

PIPE B, FEED

22712-MJP-G80

$19.61

5

GUIDE, FEED PIPE

22720-MJP-G80

$75.84

6

GEAR, PRIMARY DRIVE (43T)

23103-MJP-G80

$104.48

7

SUB-GEAR, PRIMARY (43T)

23104-HL4-000

$63.25

8

SPRING, PRIMARY DAMPER

23115-MW4-000

$2.31

9

GUIDE (30T) | Use up to Engine SN 6102189. This part replaces 23405-HL4-000.

23405-MJP-G80

$107.02

9

GUIDE (30T) | Use from Engine SN 6102190.

23405-MJP-G80

$107.02

10

GUIDE, SECOND CLUTCH GEAR (30T)

23406-HL4-000

$89.05

11

BOLT, FLANGE SOCKET (5X14)

90089-KAS-900

$2.28

12

NUT, LOCK (22MM)

90201-HL4-000

$5.16

13

WASHER (29.5X50X2)

90403-HL4-000

$4.98

14

WASHER (22X37X5)

90404-HL4-000

$7.31

15

O-RING (39.8X2.2) (ARAI)

91302-PA9-003

$4.21

16

O-RING (35X2.2)

91302-RGC-003

$2.92

17

O-RING (10.7X1.9)

91308-PY4-003

$2.18

18

O-RING (6X1.5) (N0K)

91315-PC9-004

$1.69

19

PIN, DOWEL (5X8) This part replaces 94302-05080.

94303-05080

$2.14

19

PIN, DOWEL (5X8)
