Can-Am Commander MAX 1000_LTD, 2015 Steering _23C1505 Diagram

#

Description
Price

1

Hex. Screw M6 X 30

207063044

$1.12

2

Hex. Screw M10 X 35

207103586

$0.96

3

Hex. Flange Screw M8 X 20, Scotch Grip

207582044

$1.60

4

Hex. Flange Screw M8 X 35

250000986

$2.00

5

Hex. Flange Screw M10 X 25

207602546

$2.00

6

Hex. Flange Screw M8 X 30 | DS 650 X

207683044

$1.49

7

Cotter Pin

211400017

$0.28

8

Hex. Screw M10 X 100, Scotch Grip

230500046

$7.01

9

Elastic Stop Nut M10

232500416

$1.79

10

Elastic Stop Nut M12

232521416

$1.61

11

Elastic Stop Nut M6

232561434

$1.78

11

Elastic Stop Nut M6

232561434

$1.78

12

Hex. Flange Elastic Nut M10

233201436

$2.00

13

Hex. Flange Elastic Nut M12

233221414

$5.85

14

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.27

15

Hex. Flange Elastic Nut M8

233281414

$1.31

15

Hex. Flange Elastic Nut M8

233281414

$1.31

16

Hex. Elastic Flange Nut M8

233281416

$1.43

17

Panel Nut M6 X 1.0

250100198

$1.99

18

Not Available As Spare Parts

XXX

Unavailable

20

Hex. Flange Screw M10 X 20, Scotch Grip

250000601

$1.67

21

Socket Head Screw M8 X 16

250000669

$3.00

22

Hexagonal Screw M12 X 88

250000657

$5.96

23

Torx Truss Screw M6 X 16

250000721

$1.60

24

Torx Screw M6 X 20

250000722

$1.54

25

Not Available As Spare Parts

XXX

Unavailable

26

O-Ring

293300144

$3.79

29

Bushing

293900106

$4.28

30

Tie-Rap 180 mm

414115200

$0.10

31

Steering Bushing

709402725

$3.07

32

Bushing

705600799

$3.72

33

Hardened Washer

706200281

$2.69

34

Cluster Support | X, XT

707900013

$14.76

35

Upper Cluster Cover | X, XT

707900124

$14.76

36

Not Available As Spare Parts

XXX

Unavailable

37

Not Available As Spare Parts

XXX

Unavailable

38

Not Available As Spare Parts

XXX

Unavailable

43

Adjustment Cylinder

709402506

$64.90

46

Not Available As Spare Parts

XXX

Unavailable

47

Not Available As Spare Parts

XXX

Unavailable

48

STEERING WHEEL KIT - Call your local BRP dealership | X, XT Includes 3 to 5

715001134

Unavailable

63

Ball Joint

709401134

$49.22

64

Steering Shaft

709401167

$44.00

66

Boot Kit, Pinion Side

715900235

$50.72

67

Boot Kit, Tube Side

715900236

$50.72

69

Nut Tie Rod End

715900237

$13.31

71

Boot Tube Side

709401232

$15.64

73

Power Steering

709401406

$1,558.49

74

COUPLING - Call your local BRP dealership

709401294

Unavailable

75

SUPPORT - Call your local BRP dealership

709401296

Unavailable

80

STEERING COLUMN - Call your local BRP dealership

709401326

Unavailable

81

LH DPS SUPPORT - Call your local BRP dealership

709401336

Unavailable

82

RH DPS SUPPORT - Call your local BRP dealership

709401337

Unavailable

83

Rack And Pinion Steering | Package-XT

709401390

$391.01

85

Painted Steering Wheel Support

709401391

$76.84
