Can-Am Commander MAX 1000_LTD, 2015 Air Intake _35C1505 Diagram

#

Description
Price

3

Hex. Flange Screw M6 X 25

207562544

$1.39

4

Hex. Flange Screw M6 X 20

207662044

$1.66

5

Hex. Flange Nut M6

233061414

$1.34

6

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.11

7

Flat Washer 6 mm

234062410

$0.64

8

Norma Clamp

293650077

$6.11

9

Norma Clamp

293650079

$8.89

10

Norma Clamp

293650091

$4.60

11

Norma Spring Clamp

293650213

$3.11

13

Hex. Flange Screw M6 X 25

207562544

$1.39

14

Flat Washer

250200082

$0.35

15

Drain Tube

707800080

$7.37

16

Cover Bracket

707800249

$8.45

17

Retainer Clip

707800278

$12.91

18

Intake Adaptor

707800322

$59.97

19

Air Intake Silencer Cover

707800326

$32.28

20

Air Filter

707800327

$50.34

21

Intake Adaptor

707800329

$46.12

22

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.11

23

Intake Adaptor

707800515

$64.58

24

Norma Clamp

293650091

$4.60

25

Air Intake Silencer Base

707800517

$50.74

26

Intake Adaptor

707800541

$59.97

27

Was 707800411 Hose 15.88 mm

219704438

$11.98

28

Rear Support

707800560

$16.12
