Description

Price

1

RUBBER, CANISTER MOUNTING

17411-KPP-930

$3.44

2

TUBE, AIR

17413-K87-A00

$6.50

3

TUBE, PURGE (PCSV-CANISTER)

17414-K87-L00

$17.87

4

TUBE, PURGE CONTROL VALVE JOINT

17415-K87-L00

$4.66

5

COVER A, CANISTER

17421-K87-L00

$24.40

6

CANISTER

17421-KYJ-902

$81.15

7

COVER B, CANISTER

17422-K87-L00

$23.62

8

TUBE, DRAIN

17431-K87-L00

$1.71

9

VALVE, PURGE CONTROL SOLENOID

36162-MKA-D81

$37.85

10

STAY, CANISTER

50346-K87-L00

$40.76

12

BRACKET, CANISTER

50347-K87-L00

$28.72

13

COLLAR, FR. FENDER (WHITE) (FOR RR.)

61104-428-010

Unavailable

14

RUBBER, HEADLIGHT CASE MOUNTING

61304-415-000

$3.31

15

SCREW, SPECIAL (6X14)

90111-K87-A00

$0.85

17

SCREW, VISOR SPECIAL SETTING

90115-KW7-900

$2.01

19

CLIP, BUMPER SEAL

90116-SP0-003

$4.50

20

SCREW, PAN (6X22)

90130-KYJ-900

$0.76

23

NUT, CLIP (5MM)

90677-KAN-T00

$0.59

24

SCREW-WASHER (5X10)

93892-05010-08

$1.13

25

CLAMP, TUBE (D8)

95002-40800-08

$2.07

26

CLAMP, TUBE (D12)

95002-41200-08

$2.31

27

CLIP, TUBE (C9)

95002-50000

$1.16

28

BOLT, FLANGE (6X10) BOLT, FLANGE (6X12)

95701-06010-00
