Description

Price

1

DAMPER SET, WHEEL

06410-MGS-D30

$59.16

2

SPROCKET, FINAL DRIVEN (40T)

41201-MKG-A00

$45.25

3

AXLE, RR. WHEEL

42301-K87-A00

$24.38

4

COLLAR, RR. BRAKE SIDE

42312-MGZ-J00

$13.61

5

COLLAR, L. RR. WHEEL SIDE

42313-K87-A00

$11.69

6

RING, RR. PULSER

42515-K87-L50

$51.21

7

FLANGE SUB-ASSY., RR. FINAL DRIVEN

42615-K87-A00

$256.46

8

COLLAR, RR. AXLE DISTANCE

42620-K87-A00

$16.44

9

COLLAR B, RR. AXLE DISTANCE

42625-K87-A00

$5.54

10

WHEEL SUB-ASSY., RR.

42650-K87-A00

$340.46

11

TIRE, RR. This part replaces 42711-K87-A01.

42711-K87-A02

$177.25

12

VALVE, RIM (IRC)

42753-GM9-743

$8.68

13

DISK, RR. BRAKE

43251-K87-A00

$96.34

14

WEIGHT, BALANCE (10G)

44721-MGH-H21

$3.24

14

WEIGHT, BALANCE (15G)

44722-MGH-H21

$3.86

14

WEIGHT, BALANCE (20G)

44723-MGH-H21

$4.18

15

BOLT 2, STUD (12X25)

90102-MAS-000

$4.01

16

BOLT, BRAKE DISK (8X24)

90105-KGH-900

$1.97

17

NUT, U (16MM)

90305-GW2-711

$16.36

18

NUT, U (12MM) (FUJI SEIMITSU)

90306-KGH-901

$2.64

19

WASHER, PLAIN (16.4X32X2)

90501-K87-A00

$1.54

20

PLATE, SWINGARM SIDE

90559-K87-A00

$27.74

21

BEARING, RADIAL BALL (6204UU)

91053-MGS-D31

$12.93

22

BEARING, RADIAL BALL (6303UU) (NSK)

91054-MT6-831

$38.32

23

DUST SEAL (30X47X8) (NOK) This part replaces 91253-443-761.

91253-443-762

$12.13

23

DUST SEAL (30X47X8) (NOK)
