Description

Price

1

SWITCH ASSY., FR. STOP

35340-MGS-D31

$16.62

2

CLAMP, BRAKE HOSE

43155-K2Y-A00

$1.41

3

HOSE A, FR. BRAKE

45125-K2Y-J41

$20.68

4

HOSE D, FR. BRAKE

45128-K2Y-J41

$48.38

5

STAY, FR. BRAKE HOSE

45155-K87-A00

$3.46

6

STAY B, FR. BRAKE HOSE

45160-K87-L50

$10.22

7

COLLAR, BRAKE HOSE STAY

45161-K87-L50

$1.49

8

BOOT

45504-410-003

$10.93

9

MASTER CYLINDER SUB-ASSY., FR. BRAKE (COO) (NISSIN) This part replaces 45510-MGZ-D02.

45510-MGZ-315

$111.13

9

MASTER CYLINDER SUB-ASSY., FR. BRAKE (COO) (NISSIN)

45510-MGZ-315

$111.13

10

PROTECTOR

45512-MA6-006

$3.99

11

CAP, MASTER CYLINDER (COO)

45513-HR0-305

$3.87

11

CAP, MASTER CYLINDER (COO) This part replaces 45513-KK1-771.

45513-HR0-305

$3.87

12

HOLDER, MASTER CYLINDER

45517-166-006

$12.17

13

DIAPHRAGM

45520-GE2-006

$8.35

14

PLATE, DIAPHRAGM

45521-K21-901

$2.07

15

MASTER CYLINDER SET

45530-471-831

Unavailable

16

LEVER, R. HANDLEBAR

53175-K2Y-J41

$10.33

17

GROMMET, MAIN PIPE COVER

64312-KWW-640

$0.88

18

BOLT, FLANGE (6X10)

90013-GHB-600

$4.07

19

BOLT, FLANGE (6X12) (L. SIDE ONLY)

90013-GHB-610

$2.12

20

BOLT, FLANGE (6X22)

90013-GHB-660

$2.12

21

BOLT, FLANGE (6X28)

90013-GHB-680

$0.90

22

BOLT, FLANGE (6X32)

90013-GHB-690

$0.86

23

BOLT, HANDLE LEVER PIVOT

90114-166-006

$6.04

24

BOLT, OIL (10X22) (SAGA)

90145-MS9-612

$6.82

25

WASHER, OIL BOLT

90545-300-000

$3.72

26

CIRCLIP

90651-MA5-671

$2.38

27

SCREW, FLAT (4X12)

93600-04012-0G

$0.83

27

SCREW, FLAT (4X12) This part replaces 93600-04012-1G.
