Honda CM450EA (83) MOTORCYCLE, JPN, VIN# JH2PC053-DM100001 TO JH2PC053-DM103228 CM450E REAR WHEEL Diagram

#

Description
Price

1

ADJUSTER, DRIVE CHAIN

40543-443-760

Unavailable

2

SPROCKET, FINAL DRIVEN (34T) (NOT AVAILABLE)

41200-MC2-670

Unavailable

3

WASHER (70MM)

41202-286-000

Unavailable

4

AXLE, RR. WHEEL (NOT AVAILABLE)

42301-KE7-000

Unavailable

4

AXLE, RR. WHEEL (NOT AVAILABLE) This part replaces 42301-MC0-670.

42301-KE7-000

Unavailable

5

COLLAR, RR. WHEEL SIDE (NOT AVAILABLE)

42311-413-000

Unavailable

6

HUB, RR. WHEEL (NOT AVAILABLE)

42601-413-000

Unavailable

7

COLLAR, RR. AXLE DISTANCE (NOT AVAILABLE)

42624-413-000

Unavailable

8

RIM, RR. WHEEL

42701-447-671

Unavailable

9

TIRE, RR. (4.60-16) (OHTSU) This part replaces 42710-447-732.

42711-447-732

Unavailable

9

TIRE, RR. (4.60-16) (OHTSU) This part replaces 42710-447-733.

42711-447-732

Unavailable

9

TIRE, RR. (4.60-16) (OHTSU) This part replaces 42711-447-673.

42711-447-732

Unavailable

9

TIRE, RR. (4.60-16) (OHTSU)

42711-447-732

Unavailable

9

TIRE, RR. (4.60S-16) (BS) (NOT AVAILABLE)

42711-447-771

Unavailable

9

TIRE, RR. (4.60S-16) (DUNLOP) (NOT AVAILABLE)

42711-447-772

Unavailable

10

TUBE, TIRE (120/90-16) (DUNLOP) This part replaces 08400-44700.

42712-KW3-004

$41.08

10

TUBE, TIRE (120/90-16) (DUNLOP) This part replaces 42712-447-673.

42712-KW3-004

$41.08

10

TUBE, TIRE (120/90-16) (DUNLOP) This part replaces 42712-447-771.

42712-KW3-004

$41.08

10

TUBE, TIRE (120/90-16) (DUNLOP) This part replaces 42712-447-772.

42712-KW3-004

$41.08

11

FLAP, TIRE (1.60-14) (BS)

42713-GC4-003

$6.69

11

FLAP, TIRE (1.60-14) (BS) This part replaces 42713-118-003.

42713-GC4-003

$6.69

11

FLAP, FR. TIRE (BS) This part replaces 42713-447-672.

44713-118-003

$7.20

11

FLAP, FR. TIRE (BS) This part replaces 42713-447-673.

44713-118-003

$7.20

12

BALANCER, WHEEL (20G)

44606-283-000

$8.89

13

BOLT, CHAIN ADJUSTING

90119-413-000

$3.69

14

BOLT, SPROCKET FIXING

90128-KE5-000

Unavailable

14

BOLT, SPROCKET FIXING This part replaces 90128-369-000.

90128-KE5-000

Unavailable

15

NUT, CHAIN ADJUSTING

90307-283-000

$3.39

16

NUT, HEX. (10MM)

90308-357-000

$4.85

17

CIRCLIP (OUTER) (69MM) (NOT AVAILABLE)

90665-286-000

Unavailable

18

DUST SEAL (30X55X7) (NOT AVAILABLE)

91253-413-003

Unavailable

18

DUST SEAL (30X55X7) (NOT AVAILABLE) This part replaces 91253-413-004.

91253-413-003

Unavailable

19

BEARING, RADIAL BALL (6304Z)

96120-63040-10

$22.40

20

BEARING, RADIAL BALL (6303U)

96140-63030-10

$14.48

21

SPOKE SET B (9X135)

97396-52110-P0

$3.26

22

SPOKE SET B (9X134.5)

97824-52109-P0

$3.26
