Honda CL72A MOTORCYCLE, JPN, VIN# CL72-100001 FRONT WHEEL II Diagram

#

Description
Price

1

ROD, RR. BRAKE (NOT AVAILABLE)

43423-268-000

Unavailable

2

AXLE, FR. WHEEL (NOT AVAILABLE) | Use from Frame SN 1008851

44301-283-000

Unavailable

3

HUB, FR. WHEEL This part replaces 44601-283-000.

44601-292-010

Unavailable

3

HUB, FR. WHEEL This part replaces 44601-292-000.

44601-292-010

Unavailable

3

HUB, FR. WHEEL

44601-292-010

Unavailable

4

COLLAR, FR. AXLE DISTANCE (NOT AVAILABLE) | Use from Frame SN 1008851

44620-283-000

Unavailable

5

RETAINER, FR. WHEEL BEARING (NOT AVAILABLE) | Use from Frame SN 1008851

44641-283-000

Unavailable

6

RIM, FR. WHEEL (NOT AVAILABLE) This part replaces 44701-273-010.

44701-273-315

Unavailable

6

RIM, FR. WHEEL (NOT AVAILABLE)

44701-273-315

Unavailable

7

TIRE, FR. (3.00-19) (4PR) (INOUE) (NOT AVAILABLE) This part replaces 44711-273-000.

44711-313-003

Unavailable

7

TIRE, FR. (3.00-19) (4PR) (INOUE) (NOT AVAILABLE) This part replaces 44711-290-003.

44711-313-003

Unavailable

7

TIRE, FR. (3.00-19) (4PR) (INOUE) (NOT AVAILABLE)

44711-313-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 08400-31310.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 08400-41310.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-273-000.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-290-000.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-294-004.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-300-000.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-310-004.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-312-003.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-401-681.

44712-110-003

Unavailable

8

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-413-009.

44712-110-003

Unavailable

9

FLAP, TIRE (NOT AVAILABLE)

44713-273-000

Unavailable

10

BOX ASSY., SPEEDOMETER GEAR

44800-283-000

Unavailable

11

CABLE ASSY., SPEEDOMETER (NOT AVAILABLE) | Use from Frame SN 1008851 This part replaces 44830-216-000.

44830-346-750

Unavailable

11

CABLE ASSY., SPEEDOMETER (NOT AVAILABLE) | Use from Frame SN 1008851 This part replaces 44830-273-000.

44830-346-750

Unavailable

11

CABLE ASSY., SPEEDOMETER (NOT AVAILABLE) | Use from Frame SN 1008851

44830-346-750

Unavailable

12

PANEL, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 1008851 This part replaces 45100-283-000.

45100-347-010

Unavailable

12

PANEL, FR. BRAKE (NOT AVAILABLE) This part replaces 45100-347-000.

45100-347-010

Unavailable

12

PANEL, FR. BRAKE (NOT AVAILABLE)

45100-347-010

Unavailable

13

WASHER, ANCHOR PIN (NOT AVAILABLE) | Use from Frame SN 1008851

45106-222-300

Unavailable

14

SHOE, BRAKE | Use from Frame SN 1008851 This part replaces 45120-268-020.

45120-458-305

Unavailable

14

SHOE, BRAKE | Use from Frame SN 1008851 This part replaces 45120-283-000.

45120-458-305

Unavailable

14

SHOE, BRAKE | Use from Frame SN 1008851 This part replaces 45120-458-670.

45120-458-305

Unavailable

15

CAM, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 1008851

45131-268-030

Unavailable

16

SPRING, BRAKE SHOE (NOT AVAILABLE) | Use from Frame SN 1008851 This part replaces 45133-283-000.

45133-347-000

Unavailable

16

SPRING, BRAKE SHOE (NOT AVAILABLE) | Use from Frame SN 1008851

45133-347-000

Unavailable

17

DUST SEAL, BRAKE CAM | Use from Frame SN 1008851

45134-250-000

$2.92

18

ARM A, FR. BRAKE | Use from Frame SN 1008851 This part replaces 45410-283-010.

45410-458-670

Unavailable

19

ARM, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 1008851 This part replaces 45420-268-010.

45420-458-670

Unavailable

19

ARM, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 1008851

45420-458-670

Unavailable

20

ARM, FR. BRAKE STOPPER (NOT AVAILABLE) | Use from Frame SN 1008851

45431-283-000

Unavailable

21

COLLAR, FR. BRAKE STOPPER ARM (NOT AVAILABLE) | Use from Frame SN 1008851

45432-283-000

Unavailable

22

SPRING, FR. BRAKE ARM RETURN (NOT AVAILABLE) | Use from Frame SN 1008851

45461-222-000

Unavailable

23

BOLT, FR. BRAKE STOPPER ARM (NOT AVAILABLE) | Use from Frame SN 1008851

90125-283-010

Unavailable

24

BOLT, FR. BRAKE STOPPER ARM | Use from Frame SN 1008851

90126-222-000

Unavailable

25

NUT, FR. WHEEL AXLE (NOT AVAILABLE) | Use from Frame SN 1008851

90305-283-000

Unavailable

26

WASHER, TONGUED (8.2MM) (NOT AVAILABLE) | Use from Frame SN 1008851

90532-268-000

Unavailable

27

WASHER, TORQUE (NOT AVAILABLE) | Use from Frame SN 1008851

90585-273-000

Unavailable

28

BOLT, HEX. (6X22) This part replaces 92000-06022.

92101-06022-0A

$1.54

28

BOLT, HEX. (6X22) This part replaces 92000-06022-00.

92101-06022-0A

$1.54

28

BOLT, HEX. (6X22)

92101-06022-0A

$1.54

29

SCREW, FLAT (6X12) This part replaces 93600-06012.

93600-06012-0A

$1.49

29

SCREW, FLAT (6X12)

93600-06012-0A

$1.49

30

NUT, HEX. (6MM) This part replaces 90310-KA3-711.

94001-06200-0S

$1.49

30

NUT, HEX. (6MM) This part replaces 94000-06000-0S.

94001-06200-0S

$1.49

30

NUT, HEX. (6MM) This part replaces 94001-06000.

94001-06200-0S

$1.49

30

NUT, HEX. (6MM) This part replaces 94001-06000-0S.

94001-06200-0S

$1.49

30

NUT, HEX. (6MM) This part replaces 94001-06008-0S.

94001-06200-0S

$1.49

30

NUT, HEX. (6MM)

94001-06200-0S

$1.49

30

NUT, HEX. (6MM) This part replaces 94030-06000.

94001-06200-0S

$1.49

31

PIN, COTTER (3.0X45) This part replaces 94201-30300.

94201-30450

$1.49

31

PIN, COTTER (3.0X45) This part replaces 94201-30400.

94201-30450

$1.49

31

PIN, COTTER (3.0X45)

94201-30450

$1.49

32

BEARING, RADIAL BALL (6302U)

96140-63020

$16.99

33

SPOKE B, INSIDE (9X154) (NOT AVAILABLE) | Use from Frame SN 1008851

97392-52148-1

Unavailable

34

SPOKE A, FR. (NOT AVAILABLE) | Use from Frame SN 1008851

97547-52147-1

Unavailable
