Honda CL125AA MOTORCYCLE, JPN, VIN# CL125A-300001 FRONT WHEEL Diagram

#

Description
Price

1

TIRE, RR. WHEEL (2.75-17) (INOUE) (NOT AVAILABLE) This part replaces 42711-111-006.

42711-459-005

Unavailable

1

TIRE, RR. WHEEL (2.75-17) (INOUE) (NOT AVAILABLE) This part replaces 42711-111-016.

42711-459-005

Unavailable

1

TIRE, RR. WHEEL (2.75-17) (INOUE) (NOT AVAILABLE) This part replaces 42711-243-000.

42711-459-005

Unavailable

1

TIRE, RR. WHEEL (2.75-17) (INOUE) (NOT AVAILABLE)

42711-459-005

Unavailable

2

AXLE, FR. WHEEL

44301-230-020

Unavailable

3

COLLAR, FR. SIDE WHEEL (NOT AVAILABLE)

44311-230-020

Unavailable

4

HUB, FR. WHEEL (NOT AVAILABLE) This part replaces 44601-230-010.

44601-230-020

Unavailable

4

HUB, FR. WHEEL (NOT AVAILABLE)

44601-230-020

Unavailable

5

COLLAR, FR. AXLE DISTANCE

44620-230-000

$9.90

6

RIM, WHEEL (NOT AVAILABLE)

44701-243-000

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 0Y400-03310.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 08400-03310.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 42712-102-009.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE)

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 42712-303-003.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 44712-GC4-671.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 44712-169-701.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 44712-244-000.

42712-102-761

Unavailable

7

TUBE, TIRE (2.75-17) (INOUE) This part replaces 44712-303-003.

42712-102-761

Unavailable

8

FLAP, TIRE (17) (INOUE)

42713-102-005

$6.54

8

FLAP, TIRE (17) (INOUE) This part replaces 44713-200-000.

42713-102-005

$6.54

9

GEAR, SPEEDOMETER (NOT AVAILABLE)

44806-230-020

Unavailable

10

CABLE ASSY., SPEEDOMETER

44830-126-930

Unavailable

10

CABLE ASSY., SPEEDOMETER This part replaces 44830-230-000.

44830-126-930

Unavailable

13

PANEL, FR. BRAKE (NOT AVAILABLE) | Use from Frame SN 314316

45100-230-050

Unavailable

14

SHOE, FR. BRAKE (NOT AVAILABLE)

45120-230-000

Unavailable

15

CAM, BRAKE (NOT AVAILABLE) | Use from Frame SN 308942

45131-230-020

Unavailable

15

CAM, BRAKE

45131-230-010

Unavailable

16

SPRING, FR. BRAKE SHOE This part replaces 45133-230-000.

45133-303-000

Unavailable

16

SPRING, FR. BRAKE SHOE

45133-303-000

Unavailable

17

DUST SEAL, BRAKE CAM

45134-250-000

$2.92

18

ARM, FR. BRAKE This part replaces 45410-230-020.

45410-230-030

Unavailable

18

ARM, FR. BRAKE

45410-230-030

Unavailable

19

OIL SEAL (54X66X7) This part replaces 91251-230-000.

91251-230-003

$12.60

19

OIL SEAL (54X66X7)

91251-230-003

$12.60

20

OIL SEAL (26X42X7)

91252-230-003

$10.56

21

BOLT, HEX. (6X22) This part replaces 92000-06022.

92101-06022-0A

$1.54

21

BOLT, HEX. (6X22) This part replaces 92000-06022-00.

92101-06022-0A

$1.54

21

BOLT, HEX. (6X22)

92101-06022-0A

$1.54

22

NUT, HEX. (6MM) This part replaces 90310-KA3-711.

94001-06200-0S

$1.49

22

NUT, HEX. (6MM) This part replaces 94000-06000-0S.

94001-06200-0S

$1.49

22

NUT, HEX. (6MM) This part replaces 94001-06000.

94001-06200-0S

$1.49

22

NUT, HEX. (6MM) This part replaces 94001-06000-0S.

94001-06200-0S

$1.49

22

NUT, HEX. (6MM) This part replaces 94001-06008-0S.

94001-06200-0S

$1.49

22

NUT, HEX. (6MM)

94001-06200-0S

$1.49

22

NUT, HEX. (6MM) This part replaces 94030-06000.

94001-06200-0S

$1.49

23

NUT, HEX. (14MM) This part replaces 94001-14000.

94001-14000-0S

$1.98

23

NUT, HEX. (14MM)

94001-14000-0S

$1.98

24

BEARING, RADIAL BALL (6302Z) (SOURCE: VINTAGE PARTS INC.)

96120-63020

Unavailable

25

SPOKE A (10X153) (NOT AVAILABLE)

97311-41146-1

Unavailable

26

SPOKE A (10X152.5) (NOT AVAILABLE)

97492-41145-1

Unavailable
