Honda CHF50A (05) METROPOLITAN, JPN, VIN# JH2AF600-5K300001 FRONT WHEEL Diagram

#

Description
Price

1

SHOE SET, BRAKE (JB)

06430-GET-000

$27.64

2

TIRE (90/90-10 50J) This part replaces 42711-GET-016.

42711-GET-026

$37.87

3

VALVE, RIM (IRC)

42753-GM9-743

$8.68

4

SPRING, BRAKE SHOE

43151-GC4-000

$4.76

5

AXLE, FR. WHEEL

44301-GBL-760

$10.52

6

COLLAR, FR. WHEEL SIDE

44311-GET-000

$7.57

7

COLLAR, FR. DISTANCE

44620-147-000

$8.80

8

WHEEL SUB-ASSY., FR. *NH35M* (CLOUD SILVER METALLIC)

44650-GBL-860ZA

$278.69

9

GEAR, SPEEDOMETER (14T)

44806-GS7-003

$18.68

10

PANEL SUB, FR. BRAKE *NH35M* (CLOUD SILVER METALLIC) This part replaces 45010-GET-000ZA.

45010-GET-010ZA

Unavailable

10

PANEL SUB, FR. BRAKE *NH35M* (CLOUD SILVER METALLIC)

45010-GET-010ZA

Unavailable

11

SEAL, BRAKE CAM

45134-165-890

$1.57

12

CAM, BRAKE

45141-GC1-010

$10.56

12

CAM, FR. BRAKE

45141-GC1-003

Unavailable

13

INDICATOR, FR. BRAKE

45145-GEE-000

$4.03

14

ARM, FR. BRAKE

45410-GT8-600

$13.34

15

SPRING, BRAKE ARM RETURN

45435-GC3-000

$5.90

16

NUT, U (10MM) (FUSE RASHI)

90304-GE8-003

$3.67

17

OIL SEAL (19X30.5X7) (ARAI)

90754-147-003

$5.31

18

OIL SEAL (34X42X5) (NOK)

91252-GF0-004

$6.16

19

BOLT, HEX. (5X25)

92101-05025-0A

$1.49

20

NUT, HEX. (5MM)

94001-05000-0S

$2.74

21

JOINT A, BRAKE ARM

95015-31001

$1.53

22

NUT A, BRAKE ROD ADJUSTING

95015-41000

$1.49

23

BEARING, RADIAL BALL (6200U)

96140-62000-10

$15.44
