Sea-doo Challenger, 5896, 1996 Electrical System Diagram

#

Description
Price

1

Not Available As Spare Part - Friction Washer

Unavailable

2

Battery Support

278000573

Unavailable

3

PROTECTION CAP - Call your local BRP dealership

278000020

Unavailable

4

Avdel Rivet 3/16"

293150037

$0.56

5

Not Available As Spare Parts

XXX

Unavailable

6

NGK Spark Plug BR8ES This part replaces 278000609.

219703119

$4.23

7

SPARK PLUG CAP - Call your local BRP dealership

278000237

$16.99

8

Battery Pole (Positive)

278000679

Unavailable

9

Battery Pole (Negative)

278000680

Unavailable

10

Loctite 243, 10 ml

293800060

$21.49

11

Temperature Sensor

278000194

Unavailable

12

Était/Was 293800038 Loctite 518, 50 ml

219704456

$53.99

13

Cable - Red 78"

204470001

Unavailable

14

Ground Cable 51"

278000913

Unavailable

15

Ground Cable 72"

278000915

Unavailable

16

SPARK PLUG WIRE - Call your local BRP dealership This part replaces 278001268.

278002198

Unavailable

17

Spark Plug Wire 530 (MAG)

278000322

Unavailable

18

Starter Cable 78"

278000914

Unavailable

19

Screw 1/4"

211000053

Unavailable

20

Harness Ass’y | Includes 5,6,35,60,61,62

278000747

Unavailable

21

Elevator Bolt

204000130

Unavailable

22

NUT-STOP ELASTIC MS-17830 - Call your local BRP dealership

212000005

Unavailable

23

Flat Washer M6, Stainless

234062600

$0.77

24

WASHER-LOCK TOOTHED DIN.6797A-A2 - Call your local BRP dealership

213400001

Unavailable

25

Was 293200017 Neoprene Seal

219704365

$149.99

26

Stainless, Flat Washer 8 mm

234081600

$0.55

27

HEX. NUT 1/4 - Call your local BRP dealership

211100026

Unavailable

28

Electrical Box Ass'y | Includes 28 - 29.

204470067

Unavailable

29

Gasket

293250052

Unavailable

30

Cover

278000873

Unavailable

31

Screw 1/4-20 x 5/8

211000052

Unavailable

32

Cap & Grommet

278000528

Unavailable

33

Tie Wrap 142 mm

293750002

$1.25

34

3 WIRE SUPPORT - Call your local BRP dealership

278000245

Unavailable

35

Hex. Elastic Stop Nut M6

232561600

$1.15

36

Stainless Flat Washer M6

234061600

$0.33

37

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99

38

Electrical Box Support

278000856

Unavailable
