Sea-doo Challenger 180 215 IC, 2007 Air Intake Manifold Sport Boats Diagram

Air Intake Manifold | Includes 1 to 2

420867955

$418.63

Gasket | Included in gasket kit

420950740

$3.61

BASE PLATE - Call your local BRP dealership

420851521

Unavailable

Torx Flange Screw M6 X 16

420641048

$2.46

ELECTRONIC BOX - Call your local BRP dealership | Edition 1

420664946

Unavailable

Torx Flange Screw M6 X 16

420641588

$1.74

CONNECTOR BRACKET - Call your local BRP dealership

420660402

Unavailable

Pressure Sensor

420274058

$125.34

Torx Flange Screw M6 X 16

420641048

$2.46

WIRING SUPPORT - Call your local BRP dealership

420660410

Unavailable

Torx Flange Screw M6 X 16

420641588

$1.74

Temperature Sensor This part replaces 420222423.

420222421

$31.82

Aluminum Sealing Ring

420250016

$4.41

Throttle Body

420892450

$858.93

Rubber Gasket

420950792

$8.89

Hex Screw M6 X 30

420440568

$7.10

Torx Flange Screw M6 X 25

420641238

$2.68

FUEL RAIL ASS'Y - Call your local BRP dealership

420874391

Unavailable

Fuel Injector | Includes 19 to 20

420874520

$119.57

Injector Clip

420853030

$2.46

Torx Flange Screw M6 X 25

420641238

$2.68

Not Available As Spare Part - Friction Washer

Unavailable

Intercooler This part replaces 420889653.

420889654

$428.97

PROFILE RING - Call your local BRP dealership

420631990

Unavailable

Profile Ring

420631995

$15.57

Gear Clamp

420853253

$29.22

FORMED HOSE - Call your local BRP dealership

420822173

Unavailable

Gear Clamp

420851673

$4.71

Idle Bypass Valve

420963051

$254.12

O-Ring

420631780

$3.61

Binding Head Screw M5 X 16

420440911

$11.48

Snap Ring

420845710

$3.38

Position Sensor

420866120

$77.97

Phillips Screw M4 X 16

208641660

$0.74

Flat Washer 4 mm, Stainless

234042600

$0.92

Loctite 243, 10 ml

293800060

$20.77

OIL 4T 12X1 BLEND QUART - Call your local BRP dealership

293600121

Unavailable
