Can-Am CE - Outlander 1000R EFI 4X4 - 5KRD - X MR Package - Hyper Silver, 2024 Body - Front Storage Tray Diagram

Description

Price

Rear Storage Box

708300674

$87.66

Rear Storage Box Cover

708301212

$50.74

Rear Panel

708300150

$36.89

Gasket

293200177

$15.35

Handle Latch

708201250

$11.54

English Operator Guide

219002357

Unavailable

Tool Kit

704700168

$44.99

90c

Socket Wrench 14/16MM

529000085

$6.99

90g

Screw Driver

529000021

$3.99

160

Adjustment Wrench

529000035

$2.19

170

Winch Instruction Guide

219002228

Unavailable

310

Deep Black, Rear Bumper Kit

715009056

$54.58

340

Insert Half Hex Body M6 x 1.0

250100199

$2.54

395

Flange Elastic Nut M5

233251434

$1.66

400

Panel Nut M6 X 1.0

250100198

$1.73

410

Torx Truss Screw M6 X 25

250000807

$1.74

420

LH Cargo Support

705006997

$51.51

430

RH Cargo Support

705006998

$51.51

440

Hex. Flange Screw M6 X 20

207662044

$1.66

445

Hex. Flange Screw M6 X 25

207662544

$0.53

450

Hex. Flange Screw M6 X 16

207661644

$0.61

460

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.11

465

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.11

470

Hex. Flange Screw M6 X 16, Scotch Grip

207561646

$1.56

480

LH Side Member

705018144

$28.43

490

RH Side Member

705018146

$28.43

500

Hex. Flange Screw M8 X 20

207682044

$0.92

510

Hex. Flange Elastic Nut M8

233281414

$1.14

515

Hex Flange Screw M8 X 25 S.Grip

250001016

$1.07

520

Tuflok Plastic Rivet

293150230

$1.21

540

License Plate Support

705018142

$14.75

570

Reflector Support

708200987

$4.06

580

Red, Reflector

705016982

$12.32

600

Box Ass'y

708200408

$80.74

600c

Latch

708200274

$20.77

600d

Clip | Outlander Max

269501945

$15.19

600f1

Was 715900411 Neoprene Seal | Outlander MAX

219704452

$36.89
