Can-Am CE - Maverick Sport - 1000R EFI - DPS SAS - 9GSE - Timeless Black Metallic - 60" Width, 2025 Electric - Voltage Regulator Wiring - 710008405 Diagram

Description

Price

Voltage Regulator Wiring Harness

710008405

$147.66

BN BODY

Terminal

710000913

$5.46

BN ENGINE

Terminal

515177214

$6.43

BPR

Open Barrel Terminal

278001392

$4.12

PF10

Fuse Holder Support

710007204

$8.26

PF10-F1

50A Fuse

710007318

$18.82

PF10-P1

Terminal Ring

515177799

$7.24

PF10-P2

Terminal Ring

515177799

$7.24

Female Housing, 3 Circuits

710000879

$21.42

Cap

710000882

$9.19

Seal

710001932

$3.15

Terminal

710001934

$4.51

TRL F 8S

Housing

710001928

$14.97

TRL F 8S

Lock

710001222

$1.68

TRL F 8S

Lock

710006181

$3.98

TRL F 8S

Seal

710001233

$2.55

TRL F 8S

Terminal

710001229

$3.02

TRL M 8P

Clip

710000992

$4.00

TRL M 8P

Housing

710001927

$8.57

TRL M 8P

Lock

710006181

$3.98

TRL M 8P

Seal

710001233

$2.55

TRL M 8P

Terminal

710001224

$3.02

WSS REAR F

Female Housing

515177186

$25.35

WSS REAR F

Lock

710001222

$1.68

WSS REAR F

Lock

710006398

$0.75

WSS REAR F

Seal

710001233

$2.55

WSS REAR F

Terminal

710001229

$3.02

WSS RL

Connector 2 Pins

710005669

$2.75

WSS RL

Seal

710005689

$1.83

WSS RL

Female Terminal 18-20 AWG

515178348

$1.54

WSS RR

Connector 2 Pins

710005669

$2.75

WSS RR

Seal

710005689

$1.83

WSS RR

Female Terminal 18-20 AWG

515178348

$1.54
