Can-Am CE - Maverick R Max - 996NT2 - XRC SAS - 7GTG - Loft Green Satin - 77" Width, 2026 Engine - Fuel Diagram

#

Description
Price

10

Fuel Tank Ass'y | Includes 10 to 10b

709001671

$429.99

10b

Special Nut M130

250100062

$21.99

20

Pump Gasket

293250514

$19.49

30

Fuel Pump | Includes 30 to 30b

709001057

$372.49

30a

Fuel Filter

270600113

$33.99

30b

Fuel Sender

715900424

$144.99

35

Connector Guard

707901204

$20.99

40

Hex. Flange Screw M6 X 16, Scotch Grip

207561644

$1.90

50

Norma Clamp

293650081

$12.18

55

Filler Neck Hose

709001697

$31.99

60

Filler Neck

709001220

$15.36

65

Neck Support

709001332

$16.49

70

Fuel Cap

709000868

$32.99

75

Torx Screw M6 X 20

250000722

$1.68

80

Stainless Steel Flat Washer

234062670

$2.11

85

Hex. Flange Screw M8 X 70

207687044

$7.41

86

Flat Washer 8 mm

234081410

$0.83

90

Hex. Flange Elastic Nut M8

233281414

$1.47

95

RH Retaining Strap

709001290

$43.99

100

LH Retaining Strap

709001284

$43.99

105

Carriage Bolt M8 X 75

250001199

$7.66

110

Flat Washer 8 mm

234081410

$0.83

115

Hex. Flange Elastic Nut M8

233281414

$1.47

120

Polyurethane Hose 4000MM Long | Includes 250 to 250a

219704389

$78.49

120a

Not Available As Spare Parts

XXX

Unavailable

125

Tubing 10 MM 1000MM Long

219704407

$2.79

135

Filter

709001120

$8.05

145

Polyurethane Hose 4000MM Long | Includes 250 to 250a

219704389

$78.49

145a

Not Available As Spare Parts

XXX

Unavailable

155

Fuel Tank Hose

709001209

$39.49

160

Fuel Tank Hose

709001320

$39.49
