Can-Am CE - Maverick R 996NT - XRS - 7ARK - Neo Yellow - 77" Width SAS, 2024 Suspension - Front Components Diagram

ARM_SUSPENSION UP L B-282 ASSY | Includes 10 to 10b

715010160

$264.99

Suspension Arm Bushing

706205620

$13.76

Hyper Silver, RH Upper Suspension Arm | Includes 20 to 20b This part replaces 715010035.

715010161

$434.49

Suspension Arm Bushing

706205620

$13.76

ARM_SUSPENSION LWR L B-450 ASSY | Includes 30 to 30d

715010164

$264.99

Suspension Arm Bushing

706205895

$13.76

Ball Joint

706203084

$35.99

Circlip

293370035

$2.64

Neo Yellow, RH Lower Suspension Arm Ass'y | Includes 40 to 40d

715010028

$264.99

Suspension Arm Bushing

706205895

$13.76

Ball Joint

706203084

$35.99

Circlip

293370035

$2.64

Hex. Flange Screw Din.6921 M14X2X85

250001176

$7.41

Hex. Flange Screw Din.6921 M14X2X85

250001176

$7.41

Hex. Flange Elastic Nut M14

250001166

$12.71

LH Front Knuckle Ass'y | Includes 210 to 210c

715010170

$487.49

Ball Joint

706202045

$35.99

Circlip

293370035

$2.64

RH Front Knuckle Ass'y | Includes 220 to 220c

715010171

$487.49

Ball Joint

706202045

$35.99

Circlip

293370035

$2.64

Hex Nut M12

250100239

$2.00

Hardened Washer

706200281

$2.85

Cotter Pin

211400017

$0.33

Hex. Flange Screw M10 X 50

207605056

$4.50

Flange Elastic Nut M10

233201466

$3.17

Stabilizer Bar Ass'y

706205633

$98.49

LH Front Stabilizer Link

706205574

$77.99

RH Front Stabilizer Link

706205575

$77.99

Stabilizer Bar Bushing

706205632

$8.43

Grease Fitting

408200700

$3.49

Mounting Clamp

706205649

$6.89

Hex. Flange Screw DIN.6921

250000951

$7.17

Elastic Flange Nut M12

250001195

$2.64

Elastic Flange Nut M12

250001195

$2.64

Suspension Position Sensor

710005235

$69.99

Hex. Flange Screw M5x10

207551056

$1.99

Front Sensor Support

706204861

$38.99

Hex. Flange Screw M6 X 16

207661654

$2.11

Stainless, Torx Screw M6 X 30

250000842

$2.11

Elastic Stop Nut M6 | Model-Australie, Brezil, Europe

232561494

$0.58

Link

706203429

$19.99
