Can-Am CE - Maverick R 996NT - XRS - 7ARJ - Timeless Black Metallic - 77" Width, 2024 Suspension - Front Components Diagram

ARM_SUSPENSION UP L B-282 ASSY | Includes 10 to 10b

715010160

$419.97

Suspension Arm Bushing

706205620

$13.83

Hyper Silver, RH Upper Suspension Arm | Includes 20 to 20b This part replaces 715010035.

715010161

$419.97

Suspension Arm Bushing

706205620

$13.83

Deep Black, LH Lower Suspension Arm Ass'y | Includes 30 to 30d

715010168

$516.89

Suspension Arm Bushing

706205895

$13.83

Ball Joint

706203084

$35.35

Circlip

293370035

$2.55

Deep Black, RH Lower Suspension Arm Ass'y | Includes 40 to 40d

715010169

$516.89

Suspension Arm Bushing

706205895

$13.83

Ball Joint

706203084

$35.35

Circlip

293370035

$2.55

Hex. Flange Screw Din.6921 M14X2X85

250001176

$6.08

Hex. Flange Screw Din.6921 M14X2X85

250001176

$6.08

Hex. Flange Elastic Nut M14

250001166

$10.56

LH Front Knuckle Ass'y | Includes 210 to 210c

715010170

$516.89

Ball Joint

706202045

$35.35

Circlip

293370035

$2.55

RH Front Knuckle Ass'y | Includes 220 to 220c

715010171

$516.89

Ball Joint

706202045

$35.35

Circlip

293370035

$2.55

Hex Nut M12

250100239

$1.64

Hardened Washer

706200281

$2.34

Cotter Pin

211400017

$0.25

Hex. Flange Screw M10 X 50

207605056

$3.12

Flange Elastic Nut M10

233201466

$2.63

Stabilizer Bar Ass'y

706205633

$143.05

LH Front Stabilizer Link

706205574

$88.43

RH Front Stabilizer Link

706205575

$88.43

Stabilizer Bar Bushing

706205632

$15.35

Grease Fitting

408200700

$2.80

Mounting Clamp

706205649

$6.45

Hex. Flange Screw DIN.6921

250000951

$5.47

Elastic Flange Nut M12

250001195

$2.15

Elastic Flange Nut M12

250001195

$2.15
