Description

Price

1

RADIATOR (COO) This part replaces 19010-MFJ-D01.

19010-MFJ-305

$593.86

1

RADIATOR (COO)

19010-MFJ-305

$593.86

2

NUT, SETTING (6MM)

19014-KEA-003

$2.88

3

SHROUD (COO) This part replaces 19015-MFJ-D01.

19015-MFJ-305

$62.58

3

SHROUD (COO)

19015-MFJ-305

$62.58

4

FAN, COOLING

19020-MFJ-D01

$34.78

5

MOTOR ASSY., FAN

19030-MFJ-D01

$278.64

6

CAP, RADIATOR

19037-GEE-710

$27.19

7

FILLER, NECK

19039-MFJ-D01

$28.25

8

LABEL, RADIATOR CAP

19046-PAA-A00

$2.80

12

TANK, RAD RESERVE

19101-MFJ-A42

$36.40

13

STAY, RES.TANK

19102-MFJ-A41

$13.83

14

STAY, RESERVE TANK (LOWER)

19103-MFJ-A40

$4.81

15

CAP, RESERVE TANK

19104-MB0-700

$10.92

17

STAY, RADIATOR (LOWER)

19105-MFJ-D00

$5.71

18

PLATE, R. RADIATOR HEAT GUARD

19106-MFJ-D00

$5.91

19

PLATE, L. RADIATOR HEAT GUARD

19107-MFJ-D01

$6.36

20

GUARD, RADIATOR

19108-MFJ-D00

$6.35

21

TUBE, FILLER-RESERVE TANK

19109-MJC-A00

$17.88

22

COLLAR, RADIATOR COVER

19121-KE7-000

$2.17

23

HOSE, R. RADIATOR (UPPER)

19502-MFJ-D00

$3.66

24

CLAMP, WATER HOSE (D27)

19502-MJC-A00

$8.65

25

CLAMP, WATER HOSE (35MM)

19504-MGP-000

$8.57

26

HOSE, RADIATOR

19504-MJC-A00

$30.64

27

HOSE, L. RADIATOR (UPPER)

19511-MJC-A00

$30.64

28

HOSE, L. RADIATOR (LOWER)

19512-MFJ-D00

$16.00

29

HOSE, OIL COOLER

19513-MFJ-D00

$5.52

30

JOINT, HOSE (THREE-WAY)

19514-MFJ-D00

$11.18

31

CLAMP, HOSE (30-37MM)

19516-GAG-003

$12.40

32

CLAMP, HOSE (22-29MM)

19517-ML7-691

$10.44

35

BOLT-WASHER (6X12)

90120-GHB-601

$1.75

36

NUT, SERRATE (5MM)

90315-MK3-003

$2.12

37

COLLAR, GEARSHIFT LEVER SETTING

90522-170-700

$1.77

38

CLIP, SPLASH SHIELD

90657-SB0-003

$4.90

39

CLIP, PANEL FIXING NH1 (BLACK)

91549-MW0-790ZA

$3.93

40

BOLT-WASHER (4X12)

93404-04012-08

$0.94

41

BOLT-WASHER (6X25)

93404-06025-00

$1.00

42

NUT, FLANGE (6MM)

94050-06000

$0.59

43

CLIP, TUBE (B10)

95002-02100

$1.72

44

CLIP, TUBE (C9)

95002-50000

$1.14

45

BULK HOSE, VACUUM (5X3000) (5X180)

95005-50003-30M

$18.72

46

BOLT, FLANGE (6X12)

96300-06012-00

$0.86

47

BOLT, FLANGE (6X14)

96300-06014-00
