Description

Price

1

HOSE, RR. BRAKE (NICHIRIN) This part replaces 43310-MFJ-D02.

43310-MJC-N41

$51.19

2

CONNECTOR

43503-MEE-006

$6.56

3

BOOT

43504-MB2-006

$9.01

4

MASTER CYLINDER SUB-ASSY., RR. This part replaces 43510-MFJ-305.

43510-MFJ-D01

$131.51

5

CUP, OIL

43511-KV3-831

$21.29

6

HOSE, RR. MASTER CYLINDER

43512-MFJ-D01

$14.49

7

CLAMP, MASTER CYLINDER OIL HOSE

43514-KS6-701

$11.77

8

PISTON SET, MASTER CYLINDER (NISSIN)

43520-MB2-315

$41.76

9

ROD, PUSH

43530-MCZ-006

$22.33

10

CLAMP, BRAKE HOSE BUSH

45155-MEE-000

$5.80

11

CAP, MASTER CYLINDER (COO)

45513-HR0-305

$3.87

11

CAP, MASTER CYLINDER (COO) This part replaces 45513-KK1-771.

45513-HR0-305

$3.87

12

DIAPHRAGM

45520-MG7-006

$9.52

13

PLATE, DIAPHRAGM

45521-HA2-006

$9.75

14

CIRCLIP

46182-MEL-D21

$1.77

15

TIE ROD

46505-MFJ-D01

$57.91

16

COVER, DUST

46506-MFJ-D00

$7.07

17

BOLT, SOCKET (8X30)

90125-MCJ-750

$6.07

18

BOLT, SOCKET (6X20)

90135-MEL-000

$1.48

19

BOLT, OIL (10X22)

90145-MS9-612

$6.82

20

WASHER, SPECIAL (8MM)

90443-GC8-000

$2.42

21

WASHER, OIL BOLT

90545-300-000

$3.72

22

O-RING (14.8X2.4)

91212-422-006

Unavailable

23

SCREW, FLAT (4X40)

93600-04040-1G

$0.43

24

SCREW-WASHER (4X12)

93893-04012-07

$1.22

24

SCREW-WASHER (4X12) This part replaces 93893-04012-17.
