Description

Price

1

PAN, OIL

11211-MBW-J20

Unavailable

3

PUMP ASSY., OIL

15100-MBW-000

$188.36

4

SPROCKET, OIL PUMP DRIVEN (26T)

15134-MV9-670

$27.03

5

CHAIN, OIL PUMP (52L) (DAIDO)

15140-415-003

$51.99

6

STRAINER, OIL

15153-MAL-A00

Unavailable

7

GASKET, OIL STRAINER

15154-MM5-000

$6.60

8

VALVE ASSY., RELIEF

15220-MBW-000

$38.69

9

FILTER, OIL (WAKO FILTER) This part replaces 15410-MFJ-D01.

15410-MFJ-D02

$15.84

9

FILTER, OIL (WAKO FILTER) This part replaces 15410-MCJ-003.

15410-MFJ-D02

$15.84

10

COOLER, OIL This part replaces 15700-MBW-J20.

15700-MBW-505

$279.46

11

WASHER, SPRING (24MM)

23929-PX4-700

$13.02

12

BOLT, OIL COOLER

90019-MBW-003

$30.79

13

BOLT-WASHER (6X12)

90021-MM5-000

$5.12

14

BOLT, DRAIN PLUG (12X15) This part replaces 90131-883-000.

90131-896-650

$3.98

14

BOLT, DRAIN PLUG (12X15)

90131-896-650

$3.98

15

O-RING (14.8X2.2) This part replaces 91313-MB0-003.

91313-MG7-004

$3.67

15

O-RING (14.8X2.2)

91313-MG7-004

$3.67

16

O-RING (62.4X3.1)

91316-PE7-730

$5.69

17

WASHER, DRAIN PLUG (12MM)

94109-12000

$1.49

18

PIN, DOWEL (8X14)

94301-08140

$2.25

19

BOLT, FLANGE (6X28)

95701-06028-00

$1.73

20

BOLT, FLANGE (6X35)

95701-06035-00

$1.80

21

BOLT, FLANGE (6X40)

95701-06040-00
