Honda CB750KA (80) 750 FOUR K, JPN, VIN# RC01-2100005 TO RC01-2116490 CB750K HEADLIGHT 79-80 Diagram

#

Description
Price

1

RUBBER, AIR CLEANER HOUSING SETTING

17245-107-010

$2.89

2

HEADLIGHT ASSY. (12V65/50W) (NOT AVAILABLE)

33100-425-671

Unavailable

3

RIM, HEADLIGHT (NOT AVAILABLE) | Use up to Frame SN 2104184

33101-422-671

Unavailable

3

RIM, HEADLIGHT | Use from Frame SN 2104185

33101-460-671

Unavailable

4

SCREW, BEAM ADJUSTING This part replaces 33103-346-670.

33103-MW3-610

$7.90

5

SPRING, HEADLIGHT BEAM ADJUSTING

33107-300-003

$3.01

6

NUT, HEADLIGHT BEAM ADJ.

33117-001-023

$2.39

7

WASHER, BEAM ADJUSTING

33119-371-003

$2.84

8

SET UNIT,HEAD LIG This part replaces 33120-425-671.

33120-431-505

Unavailable

8

SET UNIT,HEAD LIG This part replaces 33321-341-701.

33120-431-505

Unavailable

9

RING, RETAINING

33121-405-671

Unavailable

10

NUT, UNIT HOLDER

33128-292-670

$2.94

11

RING, SETTING

33153-422-003

Unavailable

12

REFLECTOR, FR. REFLEX This part replaces 33741-413-003.

33742-HB9-641

$13.14

12

REFLECTOR, FR. REFLEX This part replaces 33741-413-013.

33742-HB9-641

$13.14

12

REFLECTOR, FR. REFLEX

33742-HB9-641

$13.14

13

BASE, FR. REFLECTOR

33743-425-600

Unavailable

14

HORN (HIGH)

38110-MJ0-004

Unavailable

14

HORN (HIGH) This part replaces 38110-425-004.

38110-MJ0-004

Unavailable

14

HORN (HIGH) This part replaces 38110-425-601.

38110-MJ0-004

Unavailable

15

CLIP B, BRAKE HOSE (NOT AVAILABLE)

45128-425-000

Unavailable

16

CASE, HEADLIGHT

61301-425-000

Unavailable

17

COLLAR, HEADLIGHT CASE (NOT AVAILABLE)

61302-425-000

Unavailable

18

NUT, HEADLIGHT CASE

61303-425-010

Unavailable

19

COLLAR, HEADLIGHT SETTING

61304-292-000

$3.47

20

GROMMET B, HEADLIGHT

61313-422-000

$6.31

21

BRACKET, HEADLIGHT CASE (NOT AVAILABLE)

61315-425-770

Unavailable

22

BOLT, HEADLIGHT STAY (NOT AVAILABLE)

90120-425-000

Unavailable

23

COLLAR (6.2X12)

90501-425-000

$4.69

24

SCREW, PAN (3X8)

93500-03008-0H

$1.49

24

SCREW, PAN (3X8) This part replaces 93500-03008-1H.

93500-03008-0H

$1.49

25

SCREW, PAN (5X8)

93500-05008-0H

$1.49

26

SCREW, PAN (5X16)

93500-05016-0B

$1.49

27

WASHER, PLAIN (10MM)

94101-10000

$1.49

28

WASHER, SPRING (5MM)

94111-05000

$1.49

29

WASHER, SPRING (8MM)

94111-10000

$1.49

30

BOLT, FLANGE (6X10) This part replaces 95700-06010-00.

95701-06010-00

$1.49

30

BOLT, FLANGE (6X10)

95701-06010-00

$1.49

31

BOLT, FLANGE (6X12) This part replaces 95700-06012-00.

95701-06012-00

$1.62

31

BOLT, FLANGE (6X12)

95701-06012-00

$1.62
