Honda CB750A4AC (25) MOTORCYCLE, JPN, VIN# JH2RH240-SK000001 TO JH2RH240-SK099999 WIRE HARNESS Diagram

#

Description
Price

1

RECTIFIER ASSY., REGULATOR

31600-MKN-D51

$194.27

2

DIODE ASSY., THREE WAY (SUMITOMO)

31730-MAS-601

$10.81

3

WIRE HARNESS

32100-MLB-A20

Unavailable

4

SENSOR ASSY., BANK ANGLE

35160-MGS-D31

$150.05

5

HORN ASSY. (HIGH)

38110-MBV-712

$85.21

6

COVER COMP (UPPER)

38255-MLB-D00

$10.21

7

BLUETOOTH UNIT

38350-K0Z-918

$101.62

8

CUSHION

38351-MLL-D00

$4.46

9

RELAY (MICRO ISO 4P)

38501-MKP-DN1

$4.80

10

COVER, RELAY (2P)

38506-KZZ-900

$3.72

11

PGM-FI UNIT

38770-MLB-C21

$1.00

12

CHARGER UNIT, USB (TYPE-C)

38940-MKR-D11

$68.87

13

COVER, USB CHARGER (TYPE-C)

38941-MLA-A00

$7.95

14

CAP, USB CHARGER COVER

38942-MLA-A00

$3.31

15

CONTROL UNIT, BODY

38950-MLB-A21

$198.49

16

BAND, FR. NUMBER PLATE

64111-181-000

$8.11

17

BAND, TOOL

80123-GN5-900

$2.67

18

SENSOR, AMBIENT

80525-K1W-V11

$8.21

19

BOLT, FLANGE (6X16)

90020-GHB-640

$2.26

20

BOLT, FLANGE (6X14)

90025-GHB-630

$2.25

21

BOLT, FLANGE (6X22)

90026-GHB-670

$2.43

22

BOLT, FLANGE (8X14)

90036-GHB-630

$2.23

23

BAND, WIRE HARNESS

90651-K31-A61

$1.88

24

BAND, WIRE (165MM) (BLACK)

90651-KV6-003

$2.92

25

CLIP, CABLE (10MM) CLIP, CABLE (8MM)

90690-GHB-641

$2.18

26

CLIP, CABLE (15MM)

90690-GHB-651

$2.08

27

CLIP, CABLE (25MM)

90690-GHB-671

$2.18

28

STRAP, WIRE HARNESS (NOT AVAILABLE)

90690-K2K-D01

$1.49

29

CLAMP, HARNESS

90690-MEF-800

$1.49

30

CLIP, CONNECTOR (DARK BLUE)

91535-STK-003

$6.13

31

CLIP, WIRE HARNESS (BLACK)

91556-SK7-003

$5.44

32

CAP, DUMMY (6P) (RED)

91771-MKK-H11

$23.15

33

FUSE, MINI (10A)

98200-41000

$1.49

34

FUSE, MINI (15A) (Honda Code 4853438)

98200-41500

$1.49

35

FUSE, MINI (30A) (Honda Code 5359666)

98200-43000

$1.67
