Description

Price

1

SWITCH ASSY., FR. STOP

35340-MM5-600

$19.29

2

HOSE ASSY., FR. BRAKE

45126-MW3-671

Unavailable

4

BOOT

45504-410-003

$10.93

5

SPRING

45506-KA3-731

$4.61

6

MASTER CYLINDER SUB-ASSY., FR. BRAKE

45510-MW3-305

Unavailable

7

PROTECTOR

45512-MA6-006

$3.99

8

CAP, MASTER CYLINDER (NISSIN) This part replaces 45513-MM5-006.

45513-MM5-016

$20.12

9

HOLDER, MASTER CYLINDER

45517-166-006

$12.17

10

PLATE, DIAPHRAGM

45518-MM5-006

$9.57

11

DIAPHRAGM

45520-MM5-006

$13.57

12

MASTER CYLINDER SET

45530-MN9-305

$45.58

13

LEVER, R. HANDLEBAR

53175-KM9-006

$19.94

14

BOLT, HANDLE LEVER PIVOT

90114-MA5-671

$8.46

15

BOLT, OIL (10X22) This part replaces 90145-MS9-611.

90145-MS9-612

$6.82

15

BOLT, OIL (10X22)

90145-MS9-612

$6.82

16

NUT, CAP (6MM)

90201-415-000

$1.96

17

WASHER, OIL BOLT

90545-300-000

$3.72

18

CIRCLIP

90651-MA5-671

$2.38

19

SCREW, FLAT (4X12)

93600-04012-0G

$0.83

19

SCREW, FLAT (4X12) This part replaces 93600-04012-1G.
