Honda CB650A (80) MOTORCYCLE, JPN, VIN# RC05-2100002 TO RC05-2108005 STEP Diagram

#

Description
Price

1

COLLAR, INSTRUMENT SETTING

37243-323-000

Unavailable

2

PIN, STEP BAR JOINT This part replaces 50603-033-000.

50603-033-010

$3.30

2

PIN, STEP BAR JOINT

50603-033-010

$3.30

3

BAR, R. FOOTPEG

50612-413-000

Unavailable

4

WASHER, MAIN FOOTPEG

50614-413-000

Unavailable

5

BRACKET, R. STEP (NOT AVAILABLE)

50615-460-000

Unavailable

6

STOPPER, STEP RUBBER

50619-425-010

Unavailable

7

STEP ASSY., R.

50630-460-000

Unavailable

8

STEP ASSY., L. (NOT AVAILABLE)

50640-460-000

Unavailable

9

BRACKET, L. STEP (NOT AVAILABLE)

50641-460-000

Unavailable

10

BAR, L. FOOTPEG (NOT AVAILABLE)

50643-413-000

Unavailable

11

RUBBER, FOOTPEG

50661-425-670

$13.34

12

RUBBER, PILLION FOOTPEG This part replaces 50710-377-000.

50716-371-660

$14.21

12

RUBBER, PILLION FOOTPEG

50716-371-660

$14.21

14

BRACKET, PILLION STEP (NOT AVAILABLE)

50711-426-000

Unavailable

15

WASHER, PILLION FOOTPEG

50712-413-000

$3.47

17

BAR, PILLION STEP (COO) This part replaces 50715-413-000.

50715-413-305

$17.81

20

BOLT, HEX. (6X16) This part replaces 92000-06016-0A.

92101-06016-0A

$1.49

20

BOLT, HEX. (6X16) This part replaces 92100-06016-0A.

92101-06016-0A

$1.49

20

BOLT, HEX. (6X16)

92101-06016-0A

$1.49

21

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

21

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

21

WASHER, PLAIN (6MM)

94101-06800

$1.49

22

WASHER, PLAIN (8MM)

94101-08000

$1.49

23

PIN, COTTER (1.6X25) This part replaces 94201-16150.

94201-16250

$1.49

23

PIN, COTTER (1.6X25)

94201-16250

$1.49

24

PIN A, PILLION STEP

95015-81000

$2.21
