Description

Price

1

DAMPER SET, WHEEL

06410-MER-D00

$83.63

2

SPROCKET, FINAL DRIVEN (41T)

41201-MGZ-D00

$61.65

3

AXLE, RR. WHEEL

42301-MGZ-J00

$16.46

4

COLLAR, RR. BRAKE SIDE

42312-MGZ-J00

$12.21

5

COLLAR, L. RR. WHEEL SIDE

42313-MGZ-J00

$19.22

6

RING, RR. PULSER

42515-MGZ-J10

$67.76

7

FLANGE SUB-ASSY., RR. DRIVEN

42615-MGZ-D00

$134.88

8

COLLAR, RR. AXLE DISTANCE

42620-MGZ-J00

$11.74

9

COLLAR B, RR. AXLE DISTANCE

42625-MGZ-J00

$7.53

10

WHEEL SUB-ASSY., RR. (COO)

42650-MGZ-306

$913.59

11

TIRE, RR. (160/60ZR17 M/C 69W) (PIRELLI)

42711-MGZ-D82

$228.70

12

VALVE, RIM This part replaces 42753-KWF-901.

42753-K38-901

$0.51

12

VALVE, RIM

42753-K38-901

$0.51

12

VALVE, RIM (BS) VALVE, RIM (MICHELIN)

42753-ML7-003

$11.69

12

VALVE, RIM (BS) This part replaces 42753-MR4-901.

42753-ML7-003

$11.69

13

DISK, RR. BRAKE (SUNSTAR) This part replaces 43251-MGZ-J01.

43251-MGZ-J02

$76.98

14

WEIGHT, BALANCE (10G) (TOHO ZINK)

44721-SEA-N02

$3.91

14

WEIGHT, BALANCE (20G) (TOHO ZINK)

44722-SEA-N02

$4.78

14

WEIGHT, BALANCE (30G) (TOHO ZINK)

44723-SEA-N02

$5.54

14

WEIGHT, BALANCE (5G) (TOHO ZINK)

44726-SEA-N02

$1.23

14

WEIGHT, BALANCE (15G) (TOHO ZINK)

44727-SEA-N02

$2.71

14

WEIGHT, BALANCE (25G) (TOHO ZINK)

44728-SEA-N02

$5.18

15

BOLT 2, STUD (12X25)

90102-MAS-000

$3.83

16

BOLT, DISK (8X25)

90105-MGS-D30

$2.80

17

NUT, U (12MM) (FUJI SEIMITSU)

90306-KGH-901

$2.37

18

NUT, U FLANGE (16MM)

90306-MGZ-J01

$6.59

19

WASHER, RR. SWINGARM

90559-MGZ-J00

$3.99

20

BEARING, RADIAL BALL (6303UU) (FUJIKOSHI)

91051-MGZ-J01

$18.32

20

BEARING, RADIAL BALL (6303UU) (NSK)

91054-MT6-831

$35.18

21

BEARING, RADIAL BALL (6304UU)

91053-MM5-004

$29.51

22

DUST SEAL (30X52X7)

91253-442-003

$12.82

23

DUST SEAL (30X47X8) (NOK) This part replaces 91253-443-761.

91253-443-762

$11.13

23

DUST SEAL (30X47X8) (NOK)
