- CB450K1A MOTORCYCLE, JPN, VIN# CB450-3000001 TO CB450-3008955
FRONT WHEEL
Honda CB450K1A MOTORCYCLE, JPN, VIN# CB450-3000001 TO CB450-3008955 FRONT WHEEL Diagram
#
1
ROD, RR. BRAKE (NOT AVAILABLE)
43423-268-000
Unavailable
2
AXLE, FR. WHEEL (NOT AVAILABLE)
44301-283-000
Unavailable
3
HUB, FR. WHEEL This part replaces 44601-292-000.
44601-292-010
Unavailable
3
HUB, FR. WHEEL
44601-292-010
Unavailable
4
BALANCER, WHEEL (10G) | (Optional).
44608-283-000
Unavailable
5
COLLAR, FR. AXLE DISTANCE (NOT AVAILABLE)
44620-283-000
Unavailable
6
RETAINER, FR. WHEEL BEARING (NOT AVAILABLE)
44641-283-000
Unavailable
7
RIM, FR. WHEEL (NOT AVAILABLE)
44701-283-000
Unavailable
8
TIRE, FR. WHEEL (3.25-18") (DUNLOP) (NOT AVAILABLE) | Use up to Frame SN 3008955 This part replaces 44711-283-003.
44711-292-673
Unavailable
8
TIRE, FR. WHEEL (3.25-18") (DUNLOP) (NOT AVAILABLE) This part replaces 44711-292-014.
44711-292-673
Unavailable
8
TIRE, FR. WHEEL (3.25-18") (DUNLOP) (NOT AVAILABLE)
44711-292-673
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 08400-31300.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 08400-44600.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 42712-286-000.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 42712-287-000.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 42712-287-003.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 42712-437-970.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 42712-437-971.
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18)
42712-446-631
Unavailable
9
TUBE, TIRE (3.50-18) This part replaces 44712-283-000.
42712-446-631
Unavailable
10
FLAP, TIRE (18") (NOT AVAILABLE)
44713-283-000
Unavailable
11
BOX ASSY., SPEEDOMETER GEAR
44800-283-000
Unavailable
12
PANEL, FR. BRAKE (NOT AVAILABLE) This part replaces 45100-283-000.
45100-347-010
Unavailable
12
PANEL, FR. BRAKE (NOT AVAILABLE) This part replaces 45100-347-000.
45100-347-010
Unavailable
12
PANEL, FR. BRAKE (NOT AVAILABLE)
45100-347-010
Unavailable
13
WASHER, ANCHOR PIN (NOT AVAILABLE)
45106-222-300
Unavailable
14
SHOE, BRAKE This part replaces 45120-283-000.
45120-458-305
Unavailable
14
SHOE, BRAKE This part replaces 45120-458-670.
45120-458-305
Unavailable
15
CAM, FR. BRAKE (NOT AVAILABLE)
45131-268-030
Unavailable
16
SPRING, BRAKE SHOE (NOT AVAILABLE) This part replaces 45133-283-000.
45133-347-000
Unavailable
16
SPRING, BRAKE SHOE (NOT AVAILABLE)
45133-347-000
Unavailable
18
ARM A, FR. BRAKE This part replaces 45410-283-010.
45410-458-670
Unavailable
19
ARM, FR. BRAKE (NOT AVAILABLE)
45420-458-670
Unavailable
20
ARM, FR. BRAKE STOPPER (NOT AVAILABLE)
45431-292-010
Unavailable
21
SPRING, FR. BRAKE ARM RETURN (NOT AVAILABLE)
45461-222-000
Unavailable
22
BOLT, FR. BRAKE STOPPER ARM (NOT AVAILABLE)
90125-283-010
Unavailable
24
NUT, FR. WHEEL AXLE (NOT AVAILABLE)
90305-283-000
Unavailable
25
WASHER B, TONGUED (8.2MM) (NOT AVAILABLE) This part replaces 90532-292-000.
90533-286-000
Unavailable
25
WASHER B, TONGUED (8.2MM) (NOT AVAILABLE)
90533-286-000
Unavailable
26
BOLT, HEX. (6X20) This part replaces 92000-06020-0B.
92101-06020-0B
Unavailable
26
BOLT, HEX. (6X20) This part replaces 92000-06020-02.
92101-06020-0B
Unavailable
26
BOLT, HEX. (6X20) This part replaces 92018-06020-02.
92101-06020-0B
Unavailable
26
BOLT, HEX. (6X20)
92101-06020-0B
Unavailable
30
BEARING, RADIAL BALL (6302Z) (SOURCE: VINTAGE PARTS INC.)
96120-63020
Unavailable
31
SPOKE (9X144X7.6X100) (OUTSIDE)
97366-52128-1
Unavailable
32
SPOKE (9X143X8.8X84) (INSIDE) (NOT AVAILABLE)
97518-52126-1
Unavailable
