Description

Price

1

RADIATOR

19010-K0A-E11

$143.39

2

SHROUD

19015-K0A-E11

$10.98

3

SCREW, PAN (4X8.5)

19016-KEA-003

$1.62

4

FAN, COOLING

19020-KVZ-631

$29.32

5

MOTOR, FAN

19030-K0A-E11

$92.48

6

NECK, FILLER

19035-K94-T01

$28.97

7

CAP, RADIATOR

19037-GEE-710

$30.28

8

LABEL, RADIATOR CAP

19046-PAA-A00

$2.92

9

HOSE, RADIATOR (UPPER)

19062-K0A-E10

$27.20

10

HOSE, RADIATOR (LOWER)

19067-K0A-E10

$15.77

11

TUBE, RESERVE TANK BREATHER

19104-K0A-E10

$13.64

12

CAP ASSY., RESERVE TANK

19105-K94-T00

$8.16

13

GASKET ASSY., RESERVE TANK

19106-K94-T00

$4.34

14

TUBE, RADIATOR BREATHER

19107-K94-T00

$5.87

15

TANK, RADIATOR RESERVE

19110-K94-T00

$8.15

16

RUBBER, HEAT GUARD

19125-K0A-E10

$18.18

17

RUBBER, RADIATOR (LOWER)

19127-K0A-E10

$6.38

18

HOSE, FILLER NECK

19504-K94-T00

$9.75

19

CLAMP, WATER HOSE (A)

19505-KS6-700

$11.06

20

CLAMP, HOSE (22-29MM)

19517-ML7-691

$11.62

21

COLLAR, RADIATOR MOUNTING

61102-KTY-D30

$4.13

22

RUBBER, HEADLIGHT CASE MOUNTING

61304-415-000

$3.47

23

BOLT, FLANGE (6MM)

90116-KVB-900

$1.49

24

BOLT-WASHER (6X16)

90120-KCR-003

$4.39

25

NUT, CLIP (6MM)

90201-KPR-901

$1.87

26

NUT, FLANGE (3MM)

90315-MFL-003

$2.33

27

BOLT-WASHER (6X25)

93404-06025-07
