Honda CB125SA (78) MOTORCYCLE, JPN, VIN# CB125S-1500003 TO CB125S-1509345 FRONT BRAKE CALIPER 76,78 Diagram

#

Description
Price

NI

PAD SET This part replaces 06435-950-405.

45350-950-315

Unavailable

NI

PAD SET This part replaces 431A0-950-670.

45350-950-315

Unavailable

NI

PAD SET (NISSIN)

45350-950-305

Unavailable

1

JOINT, CALIPER (NOT AVAILABLE)

45104-107-720

Unavailable

2

PIN, CALIPER HOLDER

45116-107-720

Unavailable

3

COVER, DISK (NOT AVAILABLE)

45140-107-720

Unavailable

4

BODY, CALIPER *NH83L* (OFF BLACK) (NOT AVAILABLE)

45310-107-720CT

Unavailable

5

BOLT, BRAKE CABLE

45312-107-720

Unavailable

6

COVER, CALIPER *NH83L* (OFF BLACK) (NOT AVAILABLE)

45315-107-720CT

Unavailable

7

ARM, BRAKE | Use up to Frame SN 1504574

45320-324-700

Unavailable

7

ARM, BRAKE | Use from Frame SN 1504575

45320-397-720

Unavailable

8

*431A0-950-670 This part replaces 45340-107-720.

45340-950-305

Unavailable

8

*431A0-950-670 This part replaces 45340-107-721.

45340-950-305

Unavailable

8

*431A0-950-670 This part replaces 45340-950-000.

45340-950-305

Unavailable

9

PAD B (SEE KIT P/N--END OF BLOCK) (NOT AVAILABLE) This part replaces 45345-107-720.

45345-950-000

Unavailable

9

PAD B (SEE KIT P/N--END OF BLOCK) (NOT AVAILABLE) This part replaces 45345-107-721.

45345-950-000

Unavailable

9

PAD B (SEE KIT P/N--END OF BLOCK) (NOT AVAILABLE)

45345-950-000

Unavailable

10

PAD SET (SEE KIT P/N--END OF BLOCK) (NOT AVAILABLE) This part replaces 45350-107-720.

45350-107-721

Unavailable

10

PAD SET (SEE KIT P/N--END OF BLOCK) (NOT AVAILABLE)

45350-107-721

Unavailable

11

GUIDE, THRUST PLATE

45351-107-720

Unavailable

12

BOLT, ADJUSTING

45353-354-700

Unavailable

13

PIN, CABLE END | Use up to Frame SN 1504574

45355-107-720

Unavailable

13

PIN, CABLE END | Use from Frame SN 1504575

45355-397-720

Unavailable

14

SPRING, RATCHET FIXING

45357-107-720

Unavailable

15

RATCHET, ADJUSTING

45361-107-720

Unavailable

16

GASKET, CALIPER

45381-107-720

Unavailable

17

GROMMET, PAD (NOT AVAILABLE)

45383-107-720

Unavailable

18

O-RING (8.5X1.7)

90751-GK1-003

$2.70

18

O-RING (8.5X1.7) This part replaces 90751-107-720.

90751-GK1-003

$2.70

19

O-RING (36X2.4)

90752-107-720

$5.03

20

BOLT 2, STUD (8X32) This part replaces 92700-08050-0E.

92900-08032-0E

$2.17

20

BOLT 2, STUD (8X32) This part replaces 92700-08050-00.

92900-08032-0E

$2.17

20

BOLT 2, STUD (8X32) This part replaces 92700-08050-05.

92900-08032-0E

$2.17

20

BOLT 2, STUD (8X32)

92900-08032-0E

$2.17

21

NUT, HEX. (8MM)

94001-08000-0S

$1.49

22

WASHER, SPRING (8MM)

94111-08000

$1.49

23

BOLT, FLANGE (6X35) This part replaces 95700-06035-00.

95701-06035-00

$1.80

23

BOLT, FLANGE (6X35)

95701-06035-00

$1.80
