Description

Price

1

CASE A, DRIVE CHAIN

40510-MFN-D00

$5.46

2

GUIDE, RR. BRAKE AIR

40515-MFN-D00

$6.53

3

CASE B, DRIVE CHAIN

40520-MFN-D00

$4.34

4

MASTER LINK (DID) This part replaces 40535-MZ1-316.

40545-MCF-003

Unavailable

5

CHAIN, DRIVE (DID50 VA8-120ZB) (DAIDO) (STANDARD LINK 116L)

40540-MZ1-316

$305.59

6

STOPPER, TORQUE LINK

43433-KV3-951

$12.16

7

BOLT, SWINGARM PIVOT

52101-MCZ-000

$33.74

8

COLLAR A, PIVOT DISTANCE

52141-MER-D00

$10.10

9

COLLAR B, PIVOT DISTANCE

52142-MER-D00

$21.87

10

COLLAR, PIVOT DISTANCE

52143-MER-D00

$39.49

11

SLIDER, CHAIN

52170-MFN-D00

$15.66

12

GUIDE, CHAIN

52180-MFN-D00

$3.23

13

GROMMET, SWINGARM

52190-MFN-D00

$1.49

14

SWINGARM SUB-ASSY., RR.

52200-MFN-L60

$704.61

15

SCREW, SPECIAL (5X12)

90111-MFN-D00

$1.74

16

SCREW, SPECIAL (5X14)

90114-KPB-750

$2.31

17

BOLT, FLANGE (16X51)

90155-MFN-D00

$8.77

18

NUT, U (18MM)

90306-MCS-G00

$7.13

19

WASHER (20X31.5X2)

90401-MAS-000

$3.21

20

WASHER, PLAIN (16MM)

90559-HA8-000

$6.54

21

BEARING, NEEDLE

91071-MR7-003

$25.68

22

BEARING, RADIAL BALL (20X37X9)

91072-MR7-003

$18.01

23

DUST SEAL (28X37X4)

91202-MR7-003

$6.36

24

DUST SEAL (27X34X4)

91261-KZ3-861

$7.79

25

O-RING (21.8X2.4)

91355-759-003
